2018 Doosan DX120

1/9
Buy Doosan DX120 Used Excavator / 1
Buy Doosan DX120 Used Excavator / 2
Buy Doosan DX120 Used Excavator / 3
Buy Doosan DX120 Used Excavator / 4
Buy Doosan DX120 Used Excavator / 5
Buy Doosan DX120 Used Excavator / 6
Buy Doosan DX120 Used Excavator / 7
Buy Doosan DX120 Used Excavator / 8
Buy Doosan DX120 Used Excavator / 9

Product Description

This 2018 Doosan DX120 excavator represents a reliable mid-size solution for construction and earthmoving operations. Currently located in Guangxi, China, this machine comes equipped with a grapple attachment, enhancing its versatility for material handling, demolition, and forestry applications. The DX120 is known for its balanced performance in the 12-ton class, offering efficient fuel consumption and robust hydraulic systems suitable for demanding job sites.

Key features include:

  • Year of Manufacture: 2018
  • Model: Doosan DX120
  • Includes grapple attachment for enhanced functionality
  • Well-suited for excavation, loading, and material sorting tasks
  • Currently available in Guangxi, China

This unit offers an economical entry point for contractors seeking proven Doosan engineering with added attachment value. Ideal for regional construction projects, infrastructure development, or rental fleet expansion.

SpecificationsValue
No.1080366
Tonnage (tons)12
Working weight (kg)12200
Bucket capacity (m³)0.51
Boom length (mm)4300
Rod length (mm)2260
Country of originYantai
powerTraditional power
manufacturerJoint venture/Import
bucketbackhoe
Engine typeD34D
Rated power (kw/rpm)71 / 1850
Cylinder diameter × stroke (mm)98 x 113
Number of cylinders (PCS)4
Ground specific pressure (Kpa)43
Rotation speed (rpm)11.5
Climbing ability (%)35 °
Bucket digging force (kN)99 / 105
Rod digging force (kN)63.2 / 67
Maximum tractive force (kN)11.9
Travel speed (km/h)4.5 / 2.8
Turning torque (Nm)40
Type of walking hydraulic motorAxial piston hydraulic motor
Fuel Tank (L)260
Hydraulic Tank (L)152
Total transport length (mm)7315
Total transport width (mm)2540
Total transport height (mm)2775
Full cab height (mm)835
Counterweight ground clearance (mm)895
Minimum ground clearance (mm)410
Minimum turning radius of front working device (mm)2445
Back end turning radius (mm)2130
Total track length (mm)3315
Track plate width (mm)500
Total track width (mm)2490
Maximum digging radius (mm)7620
Maximum digging depth (mm)5150
Maximum excavation height (mm)7955
Maximum unloading height (mm)5640
Maximum vertical digging depth (mm)3605
Maximum excavation radius of stop surface (mm)7465
Maximum effective digging depth (mm)3605
see more

Overview

No.1080366

Brand Name:

Doosan

Model Number:

DX120

Year:

2018

Location:

Guangxi China

Pub Date
