Product Description
This 2018 Doosan DX120-9C hydraulic excavator offers reliable performance for mid-sized construction and earthmoving operations. Equipped with a grapple attachment, this machine delivers versatility for material handling, demolition, and sorting applications. The DX120-9C series features Doosan's proven engine technology and hydraulic systems designed for fuel efficiency and operational uptime.
Currently located in Guizhou, China, this unit represents solid value in the 12-ton excavator class. The grapple configuration expands capability beyond standard bucket work, making it suitable for scrap handling, forestry work, and site cleanup tasks.
- Year: 2018
- Model: Doosan DX120-9C
- Configuration: Equipped with grapple attachment
- Location: Guizhou Province, China
- Condition: Used
Contact us for detailed specifications, inspection reports, and shipping arrangements to your location.
| Specifications | Value |
|---|---|
| No. | 1081162 |
| Tonnage (tons) | 12 |
| Working weight (kg) | 12200 |
| Bucket capacity (m³) | 0.51 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | D34D |
| Rated power (kw/rpm) | 71 / 1850 |
| Bucket digging force (kN) | 99 / 105 |
| Rod digging force (kN) | 63.2 / 67 |
| Travel speed (km/h) | 4.5 / 2.8 |
| Turning torque (Nm) | 2495 |
| Total transport length (mm) | 7315 |
| Total transport width (mm) | 2540 |
| Total transport height (mm) | 2745 |
| Back end turning radius (mm) | 2130 |
| Total track length (mm) | 3315 |
| Maximum digging radius (mm) | 7620 |
| Maximum digging depth (mm) | 5150 |
| Maximum excavation height (mm) | 7955 |
| Maximum unloading height (mm) | 5640 |
| Maximum vertical digging depth (mm) | 3605 |
