Product Description
This 2017 Sany SY195C hydraulic excavator offers reliable performance for mid-size earthmoving operations. As a well-established model in Sany's lineup, the SY195C combines robust construction with efficient operation, making it suitable for general excavation, trenching, and material handling applications across construction and infrastructure projects.
Currently located in Hunan, China, this machine represents an opportunity to acquire proven Sany engineering at competitive value. The SY195C is recognized for its durable undercarriage, responsive hydraulic system, and operator-focused cab design that supports productive workdays in demanding environments.
Key features include:
- 2017 model year with operational track record
- Mid-size excavator class for versatile applications
- Sany hydraulic system for smooth operation
- Available for inspection in Hunan, China
- Suitable for construction and earthmoving contractors
Contact us for detailed specifications, current condition assessment, and export arrangements to your location.
| Specifications | Value |
|---|---|
| No. | 1080570 |
| Tonnage (tons) | 19 |
| Working weight (kg) | 20900 |
| Bucket capacity (m³) | 0.8~1.1(0.95) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | 4M50 |
| Rated power (kw/rpm) | 118/2000 |
| Maximum torque (N.m) | 580/1600 |
| Displacement (L) | 4.9 |
| Ground specific pressure (Kpa) | 47.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 103 |
| Travel speed (km/h) | 5.4/3.3 |
| Fuel Tank (L) | 340 |
| Hydraulic Tank (L) | 239 |
| Engine Oil changes (L) | 22 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4060 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3260 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Number of wheels (single side) (each) | 7 |
| Number of track plates (single side) (PCS) | 45 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 9600 |
| Maximum vertical digging depth (mm) | 6255 |
