Product Description
The 2015 Sany SY215C is a robust 21-ton class hydraulic excavator designed for demanding construction and earthmoving applications. This mid-sized crawler excavator combines Sany's proven engineering with reliable performance in the field. Currently located in Zhejiang, China, this machine represents solid value in the used equipment market.
Key features of the SY215C include:
- Operating weight approximately 21,500 kg for stable operation
- Powerful engine delivering efficient fuel consumption
- Hydraulic system optimized for precise control and productivity
- Durable undercarriage built for extended service life
- Spacious operator cabin with ergonomic controls
- Suitable for excavation, loading, and general construction tasks
This 2015 model offers buyers an opportunity to acquire proven Sany quality at an attractive price point. Ideal for contractors seeking dependable performance in medium-duty applications.
| Specifications | Value |
|---|---|
| No. | 1080517 |
| Tonnage (tons) | 21 |
| Working weight (kg) | 21900 |
| Bucket capacity (m³) | 1.1 (0.8~1.2) |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Mitsubishi 4M50 |
| Rated power (kw/rpm) | 118/2000 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 580/1600 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 4.9 |
| Ground specific pressure (Kpa) | 47.4 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 138 |
| Rod digging force (kN) | 103 |
| Travel speed (km/h) | 5.4/3.3 |
| Fuel Tank (L) | 390 |
| Hydraulic Tank (L) | 239 |
| Engine Oil changes (L) | 22 |
| Total transport length (mm) | 9680 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3440 |
| Full cab height (mm) | 3075 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3730 |
| Back end turning radius (mm) | 2900 |
| Onboard width (mm) | 2875 |
| Total track length (mm) | 4250 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3445 |
| Maximum height at minimum turning radius (mm) | 7680 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 8 |
| Number of track plates (single side) (PCS) | 47 |
| Maximum digging radius (mm) | 10280 |
| Maximum digging depth (mm) | 6600 |
| Maximum excavation height (mm) | 9600 |
| Maximum unloading height (mm) | 6730 |
