2022 XCMG XE85C

1/8
Buy XCMG XE85C Used Excavator / 1
Buy XCMG XE85C Used Excavator / 2
Buy XCMG XE85C Used Excavator / 3
Buy XCMG XE85C Used Excavator / 4
Buy XCMG XE85C Used Excavator / 5
Buy XCMG XE85C Used Excavator / 6
Buy XCMG XE85C Used Excavator / 7
Buy XCMG XE85C Used Excavator / 8

Product Description

This 2022 XCMG XE85C excavator with extended boom configuration offers reliable performance for mid-range excavation projects. The machine originates from Guangxi, China, and has been maintained to performance standards requiring no immediate inspection. XCMG's 8.5-ton class design delivers dependable hydraulic power and operator comfort for demanding work cycles.

Key specifications:

  • Operating weight: approximately 8,500 kg
  • Extended boom configuration for enhanced reach
  • Low operating hours consistent with 2022 manufacture
  • Performance-verified condition

The XE85C suits contractors requiring proven Chinese engineering in the compact excavator segment. This unit is available for immediate inspection and export coordination from Guangxi province.

SpecificationsValue
No.1081353
Tonnage (tons)8
Working weight (kg)7700/8100 (with dozer)
Bucket capacity (m³)0.34
Boom length (mm)3720
Rod length (mm)1622
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine type4JG1TPC
Rated power (kw/rpm)53.8/2150
Maximum torque (N.m/rpm)255/1800
Number of cylinders (PCS)4
Displacement (L)3.059
Ground specific pressure (Kpa)34.6/36.4 (with dozer)
Rotation speed (rpm)11
Climbing ability (%)35 °
Bucket digging force (kN)51.2
Rod digging force (kN)34.2
Maximum tractive force (kN)34.2
Travel speed (km/h)4.9/2.6
Maximum flow of main pump (l/min)198+21
Traveling Hydraulic Circuit (Mpa)27.4
Rotary Hydraulic Circuit (Mpa)20.6
Pilot Oil Circuit (MPa)3.9
Fuel Tank (L)130
Hydraulic Tank (L)115
Engine Oil changes (L)9.7
Total transport length (mm)6144
Total transport width (mm)2332
Total transport height (mm)2712
Counterweight ground clearance (mm)827
Minimum ground clearance (mm)428
Back end turning radius (mm)1805
Track gauge (mm)1870
Total track width (mm)450
Maximum digging radius (mm)6295
Maximum digging depth (mm)4130
Maximum excavation height (mm)7165
Maximum unloading height (mm)5060
Maximum vertical digging depth (mm)3500
Bulldozer lift or depth (mm)409/438
Dodging plate width × height (mm)2320 x 416
see more

Overview

No.1081353

Brand Name:

XCMG

Model Number:

XE85C

Year:

2022

Location:

Guangxi China

Pub Date
