2013 Caterpillar 329D
Product Description
Strengthen your fleet operations with this reliable 2013 Caterpillar 329D excavator, strategically positioned in Fujian for immediate deployment. Built with Japan's precision engineering standards, this 29-ton workhorse delivers consistent performance through its proven C7ACERT engine generating 152kW at 2000 RPM.
Engineered for versatility, this machine combines a substantial 1.1m³ bucket capacity with impressive reach specifications—10.6m maximum excavation radius and 7.17m digging depth. Advanced hydraulic systems operate at 3.5 MPa working pressure, supported by a high-capacity 235 L/min main pump for responsive control during demanding operations.
- Robust 6-cylinder, 7.2L displacement engine with water-cooling system
- Compact transport dimensions: 10.41m × 2.99m × 3.18m for efficient mobilization
- Generous fuel capacity (520L) minimizes downtime between refueling cycles
- Proven track record in construction and excavation applications
Perfect as a backup unit or fleet expansion, this excavator maintains Caterpillar's reputation for durability while offering cost-effective productivity for contractors managing multiple project sites simultaneously.
| Specifications | Value |
|---|---|
| No. | 989957 |
| Tonnage (tons) | 29 |
| Working weight (kg) | 29240 |
| Bucket capacity (m³) | 1.1 |
| Boom length (mm) | 6150 |
| Rod length (mm) | 3200 |
| Country of origin | Japan |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | C7ACERT |
| Rated power (kw/rpm) | 152/2000 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 110 x 127 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 7.2 |
| Rotation speed (rpm) | 10.2 |
| Climbing ability (%) | 70/35 ° |
| Travel speed (km/h) | 3.5/5.3 |
| Main overflow set pressure (Mpa) | 3.5 |
| Maximum flow of main pump (l/min) | 235 |
| Traveling Hydraulic Circuit (Mpa) | 3.5 |
| Rotary Hydraulic Circuit (Mpa) | 2.75 |
| Hydraulic crushing pipeline is standard | no |
| Working Hydraulic Circuit (Mpa) | 3.5 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Bucket cylinders - Number × diameter × stroke (mm) | 135 x 1156 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 150 x 1646 |
| Boom cylinders - Number × diameter × stroke (mm) | 140 x 1407 |
| Fuel Tank (L) | 520 |
| Hydraulic Tank (L) | 145 |
| Engine Oil changes (L) | 30 |
| Coolant (L) | 30 |
| Hydraulic System (L) | 310(including fuel tank) |
| Total transport length (mm) | 10410 |
| Total transport width (mm) | 2990 |
| Total transport height (mm) | 3180 |
| Full cab height (mm) | 3040 |
| Counterweight ground clearance (mm) | 1110 |
| Minimum ground clearance (mm) | 490 |
| Back end turning radius (mm) | 3080 |
| Total track length (mm) | 4360 |
| Track gauge (mm) | 2390 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2990 |
| Track ground length (mm) | 3490 |
| Maximum digging depth (mm) | 7170 |
| Maximum excavation height (mm) | 9990 |
| Maximum unloading height (mm) | 7020 |
| Maximum vertical digging depth (mm) | 6510 |
| Bulldozer lift or depth (mm) | No bulldozer |
| Dodging plate width × height (mm) | No bulldozer |
| Maximum excavation radius of stop surface (mm) | 10600 |
| Maximum effective digging depth (mm) | 7010 |
Overview
No.989957
Brand Name：
CaterpillarModel Number：
329DYear：
2013
Location：
Fujian China
