2015 Caterpillar 329D
Product Description
Built for demanding construction environments, this 2015 Caterpillar 329D excavator delivers proven performance with 29-ton operating weight and robust C7ACERT engine technology. Powered by a 152kW engine at 2000 rpm, this machine handles heavy-duty excavation tasks with a 1.1m³ bucket capacity and impressive 7.17m maximum digging depth.
Caterpillar's reputation for reliability makes this used excavator a smart investment. With extensive parts networks across global markets and strong resale values, Cat equipment minimizes downtime and protects your capital investment. The 329D's hydraulic system operates at 3.5 MPa working pressure with 235 L/min main pump flow, ensuring consistent performance in challenging conditions.
- 29-ton working weight with 10.6m maximum excavation radius
- C7ACERT engine: 152kW power, 7.2L displacement
- 520L fuel capacity for extended operation cycles
- Located in Jiangsu, China - ready for immediate deployment
- Caterpillar's proven parts availability and service network support
This machine combines operational efficiency with the long-term value retention that makes Caterpillar the preferred choice for equipment buyers worldwide.
| Specifications | Value |
|---|---|
| No. | 959166 |
| Tonnage (tons) | 29 |
| Working weight (kg) | 29240 |
| Bucket capacity (m³) | 1.1 |
| Boom length (mm) | 6150 |
| Rod length (mm) | 3200 |
| Country of origin | Japan |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | C7ACERT |
| Rated power (kw/rpm) | 152/2000 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 110 x 127 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 7.2 |
| Rotation speed (rpm) | 10.2 |
| Climbing ability (%) | 70/35 ° |
| Travel speed (km/h) | 3.5/5.3 |
| Main overflow set pressure (Mpa) | 3.5 |
| Maximum flow of main pump (l/min) | 235 |
| Traveling Hydraulic Circuit (Mpa) | 3.5 |
| Rotary Hydraulic Circuit (Mpa) | 2.75 |
| Hydraulic crushing pipeline is standard | no |
| Working Hydraulic Circuit (Mpa) | 3.5 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Bucket cylinders - Number × diameter × stroke (mm) | 135 x 1156 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 150 x 1646 |
| Boom cylinders - Number × diameter × stroke (mm) | 140 x 1407 |
| Fuel Tank (L) | 520 |
| Hydraulic Tank (L) | 145 |
| Engine Oil changes (L) | 30 |
| Coolant (L) | 30 |
| Hydraulic System (L) | 310(including fuel tank) |
| Total transport length (mm) | 10410 |
| Total transport width (mm) | 2990 |
| Total transport height (mm) | 3180 |
| Full cab height (mm) | 3040 |
| Counterweight ground clearance (mm) | 1110 |
| Minimum ground clearance (mm) | 490 |
| Back end turning radius (mm) | 3080 |
| Total track length (mm) | 4360 |
| Track gauge (mm) | 2390 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2990 |
| Track ground length (mm) | 3490 |
| Maximum digging depth (mm) | 7170 |
| Maximum excavation height (mm) | 9990 |
| Maximum unloading height (mm) | 7020 |
| Maximum vertical digging depth (mm) | 6510 |
| Bulldozer lift or depth (mm) | No bulldozer |
| Dodging plate width × height (mm) | No bulldozer |
| Maximum excavation radius of stop surface (mm) | 10600 |
| Maximum effective digging depth (mm) | 7010 |
Overview
No.959166
Brand Name：
CaterpillarModel Number：
329DYear：
2015
Location：
Jiangsu China
