2012 Caterpillar 336FLH
Product Description
Built for demanding excavation projects, this 2012 Caterpillar 336FLH delivers exceptional operator control and job site performance. With 36 tons of working weight and a powerful Cat C9.3 engine producing 224kW, operators benefit from precise hydraulic response and stable digging force up to 295kN maximum tractive force.
Advanced cabin design provides superior visibility for safe operation around obstacles and personnel. Hydraulic systems operate at optimized pressures—35 MPa for travel circuits and 28 MPa for rotation—ensuring smooth, controlled movements during complex maneuvers. Multiple boom configurations (2550/3200/3900mm) adapt to varied working conditions while maintaining excellent stability.
- Maximum digging depth: 10,740mm with 2.28m³ bucket capacity
- EPA Tier 4 compliant Cat C9.3 engine with air-to-air cooling
- 620L fuel tank for extended operation periods
- Compact 3500mm rear swing radius for confined spaces
Located in Jiangsu, China, this machine combines Caterpillar's proven reliability with operator-focused engineering for consistent productivity in heavy construction and excavation applications.
| Specifications | Value |
|---|---|
| No. | 972062 |
| Tonnage (tons) | 36 |
| Working weight (kg) | 36570-39370 |
| Bucket capacity (m³) | 2.28 |
| Boom length (mm) | 2550/3200/3900 |
| Rod length (mm) | 6180/6500 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar Cat C9.3(ATAAC) |
| Rated power (kw/rpm) | 224 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 115 x 149 |
| Displacement (L) | 9.3 |
| Working form | Air-to-air cooling meets EPA Tier 4 (US Environmental Protection Agency Phase 4) emission standards |
| Rotation speed (rpm) | 9.2 |
| Maximum tractive force (kN) | 295 |
| Travel speed (km/h) | 4.9 |
| Maximum flow of main pump (l/min) | 578 |
| Traveling Hydraulic Circuit (Mpa) | |35 |
| Rotary Hydraulic Circuit (Mpa) | 28 |
| Pilot pump flow (L/min) | 4.1 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-160 x 1356 |
| Fuel Tank (L) | 620 |
| Coolant (L) | 56 |
| Total transport length (mm) | 11170 |
| Total transport width (mm) | 3290/3390/3440 |
| Counterweight ground clearance (mm) | 5020 |
| Minimum ground clearance (mm) | 510 |
| Back end turning radius (mm) | 3500 |
| Total track length (mm) | |700/800/850 |
| Maximum digging depth (mm) | 10740 |
| Maximum excavation height (mm) | 7500 |
| Maximum unloading height (mm) | 7610 |
Overview
No.972062
Brand Name：
CaterpillarModel Number：
336FLHYear：
2012
Location：
Jiangsu China
