Product Description
Skip the factory lead times with this ready-to-deploy 2014 Doosan DL300 wheel loader, currently available in Jiangsu China. Powered by a robust WP6G125E332 engine delivering 92kW at 2200 RPM, this machine combines proven reliability with immediate availability for your operations.
Built for demanding construction and material handling tasks, the DL300 offers a 3-ton rated load capacity backed by 100kN of digging force. With its 10,140kg operating weight and 39.5 km/h maximum speed, this loader delivers both stability and mobility across job sites.
- 190L fuel tank for extended operation cycles
- 2,960mm maximum unloading height with 1,040mm reach
- Compact 7,008mm length fits tight spaces while maintaining power
- 30-degree maximum climbing ability handles challenging terrain
- 5,950mm turning radius for precise maneuvering
Available now for fast deployment to your site. Contact us today to arrange inspection and delivery from our Jiangsu location.
| Specifications | Value |
|---|---|
| No. | 971528 |
| Engine type | WP6G125E332 |
| Rated power (kw/rpm) | 92/2200 |
| Maximum torque (N.m) | 540/1400~1600 |
| Bucket capacity (m³) | |
| Rated load (tons) | |
| Rated load (kg) | 3000 |
| Digging force (lifting force) (kN) | 100 |
| Machine operating weight (kg) | 10140 |
| Max - Unloading height (mm) | 2960 |
| Unloading distance (mm) | 1040 |
| Maximum tractive force (kN) | 100 |
| Maximum climbing ability (°) | 30 |
| Fuel Tank (L) | 190 |
| Hydraulic Tank (L) | 100 |
| Engine Oil (L) | 18 |
| Wheelbase (mm) | 2850 |
| Wheel base (mm) | 1850 |
| Minimum ground clearance (mm) | 371.5 |
| Machine length (mm) | 7008 |
| Machine width (mm) | 2520 |
| Machine height (mm) | 3222 |
| Steering Angle | 38 |
| Turning radius - Outside of bucket (mm) | 5950 |
| Ternary sum (s) | 9.2 |
| Maximum speed (km/h) | 39.5 |
