Product Description
Engineered with Doosan's WP6G125E332 powerplant delivering 92kW at 2200 RPM and 540 N·m peak torque, this 2016 DL300 wheel loader represents proven hydraulic excellence in the compact loader segment. Advanced hydraulic systems generate 100kN digging force while maintaining precise control across all operating parameters.
Key technical specifications demonstrate superior engineering:
- 10,140kg operating weight optimized for stability and performance
- 3,000kg rated payload capacity with 2,960mm maximum unloading height
- 39.5km/h maximum transport speed with 5,950mm turning radius
- 190L fuel capacity supporting extended operational cycles
- 30-degree maximum climbing capability on challenging terrain
Located in Fujian Province, this machine combines Doosan's reputation for hydraulic precision with robust construction standards. The DL300 series incorporates advanced load-sensing hydraulics and reinforced structural components, ensuring consistent performance in demanding applications. Comprehensive maintenance records available upon request.
| Specifications | Value |
|---|---|
| No. | 987440 |
| Engine type | WP6G125E332 |
| Rated power (kw/rpm) | 92/2200 |
| Maximum torque (N.m) | 540/1400~1600 |
| Bucket capacity (m³) | |
| Rated load (tons) | |
| Rated load (kg) | 3000 |
| Digging force (lifting force) (kN) | 100 |
| Machine operating weight (kg) | 10140 |
| Max - Unloading height (mm) | 2960 |
| Unloading distance (mm) | 1040 |
| Maximum tractive force (kN) | 100 |
| Maximum climbing ability (°) | 30 |
| Fuel Tank (L) | 190 |
| Hydraulic Tank (L) | 100 |
| Engine Oil (L) | 18 |
| Wheelbase (mm) | 2850 |
| Wheel base (mm) | 1850 |
| Minimum ground clearance (mm) | 371.5 |
| Machine length (mm) | 7008 |
| Machine width (mm) | 2520 |
| Machine height (mm) | 3222 |
| Steering Angle | 38 |
| Turning radius - Outside of bucket (mm) | 5950 |
| Ternary sum (s) | 9.2 |
| Maximum speed (km/h) | 39.5 |
