Product Description
Built for immediate deployment, this 2010 Doosan DX60 compact excavator delivers reliable performance across construction and utility projects. With 6-ton operating capacity and proven Yanmar 4TNV94L engine producing 39.7kW, this machine handles demanding excavation, grading, and demolition tasks with precision.
Key operational specifications include:
- Maximum digging depth of 3,805mm for deep foundation work
- 6,150mm maximum reach radius covering extensive work areas
- 44kN bucket digging force for breaking through compacted materials
- Compact 2,000mm transport width enabling access to confined job sites
- 115L fuel capacity supporting extended operational periods
Currently positioned in Jiangsu, China, this excavator features backhoe configuration optimized for trenching, utility installation, and site preparation. Hydraulic system operates at 21.6 Mpa working pressure with dual main pumps delivering consistent performance. Track-mounted design provides 78% climbing capability on slopes up to 30 degrees, making it suitable for challenging terrain conditions.
| Specifications | Value |
|---|---|
| No. | 951788 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5700 |
| Bucket capacity (m³) | 0.21 |
| Boom length (mm) | 3000 |
| Rod length (mm) | 1600 |
| Country of origin | Yantai |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar YANMAR 4TNV94L |
| Rated power (kw/rpm) | 39.7 / 2200 |
| Maximum torque (N.m) | 20-22/1100 |
| Rotation speed (rpm) | 9.5 |
| Climbing ability (%) | 78/30 degrees |
| Bucket digging force (kN) | 44 |
| Rod digging force (kN) | 28 |
| Maximum tractive force (kN) | 58 |
| Travel speed (km/h) | 4.1 / 3.0 |
| Turning torque (Nm) | 20 ~ 22 |
| Maximum flow of main pump (l/min) | 60.5 x 2 + 36 |
| Traveling Hydraulic Circuit (Mpa) | 21.6 |
| Working Hydraulic Circuit (Mpa) | 21.6 |
| Fuel Tank (L) | 115 |
| Total transport length (mm) | 5850 |
| Total transport width (mm) | 2000 |
| Total transport height (mm) | 2575(to top of cab) |
| Minimum ground clearance (mm) | 400 |
| Back end turning radius (mm) | 1650 |
| Total track length (mm) | 2540 |
| Maximum digging radius (mm) | 6150 |
| Maximum digging depth (mm) | 3805 |
| Maximum excavation height (mm) | 5790 |
| Maximum unloading height (mm) | 4065 |
| Maximum vertical digging depth (mm) | 3038 |
| Dodging plate width × height (mm) | 2000 x 350 |
