Product Description
Maximize your construction budget with this 2022 Doosan DX60 excavator, delivering professional-grade performance at a fraction of new equipment costs. Built in Yantai with proven Yanmar 4TNV94L engine technology, this 6-ton machine combines reliability with smart economics.
Key specifications include 0.21m³ bucket capacity, 6150mm maximum digging radius, and 3805mm maximum digging depth. The robust hydraulic system generates 44kN bucket digging force and 28kN rod digging force, while the efficient 39.7kW engine provides optimal fuel economy from its 115L tank.
- Compact 2000mm transport width fits standard trailers
- Superior 78% climbing ability handles challenging terrain
- Dual-speed travel system (4.1/3.0 km/h) for versatility
- 1650mm rear swing radius enables tight-space operation
- 21.6 MPa hydraulic pressure ensures consistent performance
Located in Shandong, China, this well-maintained unit offers immediate productivity gains without the depreciation hit of new equipment. Smart contractors choose proven performance over premium pricing.
| Specifications | Value |
|---|---|
| No. | 966261 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5700 |
| Bucket capacity (m³) | 0.21 |
| Boom length (mm) | 3000 |
| Rod length (mm) | 1600 |
| Country of origin | Yantai |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar YANMAR 4TNV94L |
| Rated power (kw/rpm) | 39.7 / 2200 |
| Maximum torque (N.m) | 20-22/1100 |
| Rotation speed (rpm) | 9.5 |
| Climbing ability (%) | 78/30 degrees |
| Bucket digging force (kN) | 44 |
| Rod digging force (kN) | 28 |
| Maximum tractive force (kN) | 58 |
| Travel speed (km/h) | 4.1 / 3.0 |
| Turning torque (Nm) | 20 ~ 22 |
| Maximum flow of main pump (l/min) | 60.5 x 2 + 36 |
| Traveling Hydraulic Circuit (Mpa) | 21.6 |
| Working Hydraulic Circuit (Mpa) | 21.6 |
| Fuel Tank (L) | 115 |
| Total transport length (mm) | 5850 |
| Total transport width (mm) | 2000 |
| Total transport height (mm) | 2575(to top of cab) |
| Minimum ground clearance (mm) | 400 |
| Back end turning radius (mm) | 1650 |
| Total track length (mm) | 2540 |
| Maximum digging radius (mm) | 6150 |
| Maximum digging depth (mm) | 3805 |
| Maximum excavation height (mm) | 5790 |
| Maximum unloading height (mm) | 4065 |
| Maximum vertical digging depth (mm) | 3038 |
| Dodging plate width × height (mm) | 2000 x 350 |
