Product Description
Built for demanding excavation work, this 2013 Doosan DX80 delivers reliable 8-ton performance with exceptional operator control. Powered by a robust Yanmar 4TNV98 engine producing 41.4kW, this compact excavator combines precision handling with impressive digging capabilities.
Operators benefit from superior cabin visibility and ergonomic controls that enhance productivity during extended work sessions. With 56kN bucket digging force and 4165mm maximum digging depth, this machine tackles challenging terrain while maintaining stability through its optimized 1770mm track gauge design.
- Compact 6000mm transport length for easy site mobility
- Dual hydraulic pump system (75.6L/min each) ensures smooth operation
- 30-degree climbing ability handles steep grades confidently
- 145L fuel tank provides extended operating time
- Low ground pressure (37kPa) minimizes surface damage
Currently located in Guizhou, this well-maintained excavator represents proven Doosan engineering with the reliability operators demand for consistent performance across diverse job sites.
| Specifications | Value |
|---|---|
| No. | 991081 |
| Tonnage (tons) | 8 |
| Working weight (kg) | 7900 |
| Bucket capacity (m³) | 0.30 ~ 0.32 |
| Country of origin | Yantai, China |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar 4TNV98 VDB24 |
| Rated power (kw/rpm) | 41.4 / 2100 |
| Cylinder diameter × stroke (mm) | 98 x 110 |
| Number of cylinders (PCS) | 4 |
| Working form | 4-stroke, water-cooled, direct injection; Naturally aspirated, air-cooled |
| Ground specific pressure (Kpa) | 37 |
| Rotation speed (rpm) | 11.5 |
| Climbing ability (%) | 30 ° |
| Bucket digging force (kN) | 56 |
| Rod digging force (kN) | 41 |
| Maximum tractive force (kN) | 63 |
| Travel speed (km/h) | 4.9 / 3.1 |
| Turning torque (Nm) | 24.2 |
| Maximum flow of main pump (l/min) | 75.6 * 2 + 18.7 |
| Traveling Hydraulic Circuit (Mpa) | 28 |
| Working Hydraulic Circuit (Mpa) | 28 |
| Fuel Tank (L) | 145 |
| Total transport length (mm) | 6000 |
| Total transport width (mm) | 2290 |
| Total transport height (mm) | 2685 |
| Full cab height (mm) | 2,690 |
| Counterweight ground clearance (mm) | 825 |
| Back end turning radius (mm) | 1800 |
| Onboard width (mm) | 2,200 |
| Total track length (mm) | 2750 |
| Track gauge (mm) | 1,770 |
| Track plate width (mm) | 450 |
| Total track width (mm) | 2,220 |
| Maximum digging radius (mm) | 6350 |
| Maximum digging depth (mm) | 4165 |
| Maximum excavation height (mm) | 7120 |
| Maximum unloading height (mm) | 5115 |
| Maximum vertical digging depth (mm) | 3328 |
| Dodging plate width × height (mm) | 2200 x 418 |
