Product Description
Built for immediate deployment, this 2014 Doosan DX80 excavator delivers reliable 8-ton performance across construction and demolition sites. Powered by a proven Yanmar 4TNV98 engine generating 41.4kW, this machine handles demanding excavation tasks with 56kN bucket digging force and 4.165m maximum dig depth.
Key operational specifications include:
- 0.30-0.32m³ bucket capacity for efficient material handling
- 6.35m maximum reach radius covering extensive work areas
- 7.12m maximum excavation height for elevated operations
- 30° climbing capability on challenging terrain
- 145L fuel tank supporting extended work cycles
Currently located in Putian, Fujian, this compact excavator fits standard transport requirements at 6.0m length and 2.29m width. With dual hydraulic pumps delivering 75.6L/min flow rate and 28MPa working pressure, operators can execute precise grading, trenching, and demolition work. Ready for immediate site deployment with proven Doosan engineering reliability.
| Specifications | Value |
|---|---|
| No. | 989774 |
| Tonnage (tons) | 8 |
| Working weight (kg) | 7900 |
| Bucket capacity (m³) | 0.30 ~ 0.32 |
| Country of origin | Yantai, China |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar 4TNV98 VDB24 |
| Rated power (kw/rpm) | 41.4 / 2100 |
| Cylinder diameter × stroke (mm) | 98 x 110 |
| Number of cylinders (PCS) | 4 |
| Working form | 4-stroke, water-cooled, direct injection; Naturally aspirated, air-cooled |
| Ground specific pressure (Kpa) | 37 |
| Rotation speed (rpm) | 11.5 |
| Climbing ability (%) | 30 ° |
| Bucket digging force (kN) | 56 |
| Rod digging force (kN) | 41 |
| Maximum tractive force (kN) | 63 |
| Travel speed (km/h) | 4.9 / 3.1 |
| Turning torque (Nm) | 24.2 |
| Maximum flow of main pump (l/min) | 75.6 * 2 + 18.7 |
| Traveling Hydraulic Circuit (Mpa) | 28 |
| Working Hydraulic Circuit (Mpa) | 28 |
| Fuel Tank (L) | 145 |
| Total transport length (mm) | 6000 |
| Total transport width (mm) | 2290 |
| Total transport height (mm) | 2685 |
| Full cab height (mm) | 2,690 |
| Counterweight ground clearance (mm) | 825 |
| Back end turning radius (mm) | 1800 |
| Onboard width (mm) | 2,200 |
| Total track length (mm) | 2750 |
| Track gauge (mm) | 1,770 |
| Track plate width (mm) | 450 |
| Total track width (mm) | 2,220 |
| Maximum digging radius (mm) | 6350 |
| Maximum digging depth (mm) | 4165 |
| Maximum excavation height (mm) | 7120 |
| Maximum unloading height (mm) | 5115 |
| Maximum vertical digging depth (mm) | 3328 |
| Dodging plate width × height (mm) | 2200 x 418 |
