Product Description
Built for reliability and engineered to last, this 2016 Doosan DX80 excavator delivers proven performance with 8-ton capacity and robust Yanmar 4TNV98 engine producing 41.4kW of power. Operating from Hubei, China, this compact workhorse features 0.30-0.32 m³ bucket capacity and impressive 56kN digging force, making it ideal for construction, landscaping, and utility projects.
Doosan's reputation for durability translates directly into superior resale value and readily available parts support across global markets. With 4,165mm maximum digging depth and 6,350mm reach, this machine handles demanding applications while maintaining fuel efficiency through its 145L tank capacity.
- Proven Yanmar engine with 4-stroke, water-cooled design
- Compact 2,290mm transport width for easy site mobility
- Strong hydraulic system with dual 75.6 L/min pumps
- Established dealer network ensures parts availability
- Doosan brand heritage maintains strong resale values
Smart buyers choose Doosan for long-term value retention and operational dependability in the competitive used equipment market.
| Specifications | Value |
|---|---|
| No. | 939826 |
| Tonnage (tons) | 8 |
| Working weight (kg) | 7900 |
| Bucket capacity (m³) | 0.30 ~ 0.32 |
| Country of origin | Yantai, China |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar 4TNV98 VDB24 |
| Rated power (kw/rpm) | 41.4 / 2100 |
| Cylinder diameter × stroke (mm) | 98 x 110 |
| Number of cylinders (PCS) | 4 |
| Working form | 4-stroke, water-cooled, direct injection; Naturally aspirated, air-cooled |
| Ground specific pressure (Kpa) | 37 |
| Rotation speed (rpm) | 11.5 |
| Climbing ability (%) | 30 ° |
| Bucket digging force (kN) | 56 |
| Rod digging force (kN) | 41 |
| Maximum tractive force (kN) | 63 |
| Travel speed (km/h) | 4.9 / 3.1 |
| Turning torque (Nm) | 24.2 |
| Maximum flow of main pump (l/min) | 75.6 * 2 + 18.7 |
| Traveling Hydraulic Circuit (Mpa) | 28 |
| Working Hydraulic Circuit (Mpa) | 28 |
| Fuel Tank (L) | 145 |
| Total transport length (mm) | 6000 |
| Total transport width (mm) | 2290 |
| Total transport height (mm) | 2685 |
| Full cab height (mm) | 2,690 |
| Counterweight ground clearance (mm) | 825 |
| Back end turning radius (mm) | 1800 |
| Onboard width (mm) | 2,200 |
| Total track length (mm) | 2750 |
| Track gauge (mm) | 1,770 |
| Track plate width (mm) | 450 |
| Total track width (mm) | 2,220 |
| Maximum digging radius (mm) | 6350 |
| Maximum digging depth (mm) | 4165 |
| Maximum excavation height (mm) | 7120 |
| Maximum unloading height (mm) | 5115 |
| Maximum vertical digging depth (mm) | 3328 |
| Dodging plate width × height (mm) | 2200 x 418 |
