Product Description
Engineered with precision hydraulics and powered by a robust ISUZU CC-4BG1TC engine delivering 66kW at 2150 rpm, this 2016 Hitachi ZX120 excavator represents proven Japanese engineering excellence. Built in Hefei, Anhui Province through joint venture manufacturing, this 12-ton machine combines reliability with performance across demanding jobsites.
Technical specifications showcase superior capability:
- Variable piston pump hydraulic system with 34.3 Mpa main overflow pressure
- Impressive 8.27m maximum digging radius and 5.57m maximum depth
- Powerful digging forces: 99kN bucket force, 65kN rod force
- 0.52m³ bucket capacity optimized for versatility
- Water-cooled 4-cylinder engine with 4.329L displacement
Located in Jiangxi Province, this ZX120 demonstrates Hitachi's commitment to durability through advanced hydraulic motor technology and precise ground pressure distribution at 37 Kpa. With dual travel speeds (3.4/5.5 km/h) and 70% climbing capability, this excavator delivers consistent performance in challenging terrain while maintaining the build quality that defines the ZX series.
| Specifications | Value |
|---|---|
| No. | 990597 |
| Tonnage (tons) | 12 |
| Working weight (kg) | 12200 |
| Bucket capacity (m³) | 0.52 |
| Boom length (mm) | 4.6 |
| Rod length (mm) | 2.52 |
| Country of origin | Hefei, Anhui Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | ISUZU CC-4BG1TC |
| Rated power (kw/rpm) | 66/2150 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 4.329 |
| Working form | Direct injection |
| Ground specific pressure (Kpa) | 37 |
| Rotation speed (rpm) | 13.7 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 99 |
| Rod digging force (kN) | 65 |
| Travel speed (km/h) | 3.4/5.5 |
| Main overflow set pressure (Mpa) | 34.3 |
| Rotary hydraulic motor type | Quantitative plunger pump ×1 |
| Type of walking hydraulic motor | Variable piston pump ×2 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Variable piston pump ×2+ gear pump ×1 |
| Fuel Tank (L) | 250 |
| Hydraulic Tank (L) | 69(Full box 130) |
| Engine Oil changes (L) | 15.8 |
| Total transport length (mm) | 7610 |
| Total transport width (mm) | 2490 |
| Total transport height (mm) | 2740 |
| Full cab height (mm) | 2740 |
| Counterweight ground clearance (mm) | 890 |
| Minimum ground clearance (mm) | 440 |
| Back end turning radius (mm) | 2130 |
| Total track length (mm) | 3580 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Total track width (mm) | 2490 |
| Track ground length (mm) | 2880 |
| Maximum digging radius (mm) | 8270 |
| Maximum digging depth (mm) | 5570 |
| Maximum excavation height (mm) | 8570 |
| Maximum unloading height (mm) | 6160 |
| Maximum vertical digging depth (mm) | 5020 |
| Bulldozer lift or depth (mm) | No bulldozer |
