Product Description
Skip the factory lead times with this proven 2013 Hitachi ZX60-5G compact excavator, available now from Yunnan China. Built for reliable performance, this 6-ton machine delivers 42.4kW of power through its robust Yanmar 4TNV98-AVHBW engine, ensuring consistent operation across demanding jobsites.
Engineered for versatility, the ZX60-5G features a 0.24m³ bucket capacity and impressive reach specifications: 6.25m maximum digging radius and 3.85m maximum digging depth. Advanced hydraulic systems operate at 24.5 MPa working pressure, providing precise control for excavation, loading, and material handling tasks.
- Compact dimensions (6.06m × 2.06m × 2.09m) for tight workspace access
- 70% climbing ability handles challenging terrain conditions
- Variable travel speeds (0-4.5 km/h) optimize productivity and fuel efficiency
- 120L fuel tank capacity extends operational runtime
Ready for immediate deployment to your construction site. Fast shipping from Yunnan ensures minimal downtime between purchase and productive operation. Contact us today for availability and logistics coordination.
| Specifications | Value |
|---|---|
| No. | 968881 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5960 |
| Bucket capacity (m³) | 0.24 |
| Country of origin | Hefei (Capital of Anhui Province) |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar 4TNV98-AVHBW |
| Rated power (kw/rpm) | 42.4/2100 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 98 x 110 |
| Maximum torque (N.m) | 236 |
| Number of cylinders (PCS) | 4 |
| Working form | Four-stroke, water-cooled, direct injection |
| Rotation speed (rpm) | 9.1 |
| Climbing ability (%) | 70% (35°) |
| Maximum tractive force (kN) | 38.5 |
| Travel speed (km/h) | 0-4.5/0-2.5 |
| Turning torque (Nm) | 10 |
| Rotary hydraulic motor type | 1 axial plunger motor |
| Type of walking hydraulic motor | 2 variable axial piston motors |
| Traveling Hydraulic Circuit (Mpa) | 24.5 |
| Rotary Hydraulic Circuit (Mpa) | 17.6 |
| Main pump type | 3 variable axial piston pumps |
| Working Hydraulic Circuit (Mpa) | 24.5 |
| Fuel Tank (L) | 120 |
| Hydraulic Tank (L) | 60 |
| Coolant (L) | 8 |
| Hydraulic System (L) | 93 |
| Total transport length (mm) | 6060 |
| Total transport width (mm) | 2060 |
| Total transport height (mm) | 2085 |
| Full cab height (mm) | 2475 |
| Counterweight ground clearance (mm) | 620 |
| Minimum ground clearance (mm) | 310 |
| Minimum turning radius of front working device (mm) | 2510 |
| Back end turning radius (mm) | 1650 |
| Onboard width (mm) | 2060 |
| Track gauge (mm) | 1600 |
| Track plate width (mm) | 400 |
| Maximum digging radius (mm) | 6250 |
| Maximum digging depth (mm) | 3850 |
| Maximum excavation height (mm) | 4080 |
| Maximum vertical digging depth (mm) | 3440 |
| Dodging plate width × height (mm) | 200 x 400 |
| Maximum excavation radius of stop surface (mm) | 6130 |
