Product Description
Skip the factory lead times with this ready-to-deploy 2017 Hitachi ZX70 excavator, strategically located in Jiangsu China for immediate shipment. Operating at 7 tons with a robust ISUZU CC-4JG1 engine delivering 40.5kW of reliable power, this compact workhorse tackles demanding excavation tasks with precision and efficiency.
Built for versatility, this machine features a 0.3m³ bucket capacity and impressive digging specifications: 6,320mm maximum reach, 4,170mm digging depth, and 55kN bucket digging force. Advanced hydraulic systems with variable piston pumps ensure smooth operation across diverse job sites.
- Available now from Jiangsu - no manufacturing delays
- Compact 2,260mm transport width for easy site access
- Proven ISUZU engine with water-cooling system
- 135L fuel capacity for extended operation cycles
- Fast deployment to your construction site
With 6,510kg working weight and 30kPa ground pressure, this excavator delivers optimal performance while minimizing surface damage. Ready for immediate inspection and rapid delivery to accelerate your project timeline.
| Specifications | Value |
|---|---|
| No. | 957780 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 6510 |
| Bucket capacity (m³) | 0.3 |
| Boom length (mm) | 3.72 |
| Rod length (mm) | 1.62(reinforced type) |
| Country of origin | Hefei, Anhui Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | ISUZU CC-4JG1 |
| Rated power (kw/rpm) | 40.5/2000 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.318 |
| Working form | Direct injection |
| Ground specific pressure (Kpa) | 30 |
| Rotation speed (rpm) | 11.3 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 55 |
| Rod digging force (kN) | 38 |
| Travel speed (km/h) | 3.4/5.0 |
| Main overflow set pressure (Mpa) | 31.4 |
| Rotary hydraulic motor type | Variable piston pump ×1 |
| Type of walking hydraulic motor | Variable piston pump ×2 |
| Main pump type | Variable piston pump ×3+ gear pump ×1 |
| Fuel Tank (L) | 135 |
| Hydraulic Tank (L) | 60(over 100) |
| Engine Oil changes (L) | 12 |
| Total transport length (mm) | 6080 |
| Total transport width (mm) | 2260 |
| Total transport height (mm) | 2600 |
| Full cab height (mm) | 2600 |
| Counterweight ground clearance (mm) | 760 |
| Minimum ground clearance (mm) | 360 |
| Back end turning radius (mm) | 1750 |
| Total track length (mm) | 2765 |
| Track gauge (mm) | 1750 |
| Track plate width (mm) | 450 |
| Total track width (mm) | 2200 |
| Track ground length (mm) | 2140 |
| Maximum digging radius (mm) | 6320 |
| Maximum digging depth (mm) | 4170 |
| Maximum excavation height (mm) | 7150 |
| Maximum unloading height (mm) | 5060 |
| Maximum vertical digging depth (mm) | 3730 |
| Bulldozer lift or depth (mm) | No bulldozer |
