Product Description
Built for demanding construction environments, this 2016 Hyundai R385LC-9T excavator delivers proven performance with 38-ton capacity and robust Cummins QSM11-C engine generating 263kW of power. Operating from Jiangsu, China, this machine features impressive specifications including 11,910mm maximum digging radius, 7,120mm digging depth, and substantial 228.5kN bucket digging force.
Hyundai's reputation for reliability makes this excavator a strategic investment in the used equipment market. Key advantages include:
- Extensive parts network ensures minimal downtime and cost-effective maintenance
- Strong resale value retention compared to lesser-known brands
- Proven hydraulic system with dual 288 l/min pumps for consistent performance
- Advanced six-cylinder turbocharged engine with intercooled EFI technology
With 1.9m³ bucket capacity and efficient hydraulic circuits operating at 330 MPa working pressure, this R385LC-9T handles heavy-duty applications while maintaining operational efficiency. Hyundai's established service infrastructure and readily available genuine parts ensure long-term operational success for contractors seeking dependable heavy machinery.
| Specifications | Value |
|---|---|
| No. | 955037 |
| Tonnage (tons) | 38 |
| Working weight (kg) | 38600 |
| Bucket capacity (m³) | 1.9 |
| Boom length (mm) | 6500 |
| Rod length (mm) | 2800 |
| Country of origin | Jiangsu (Province) |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Cummins QSM11-C |
| Rated power (kw/rpm) | 263/1900 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 114 x 145 |
| Maximum torque (N.m/rpm) | 1788.5 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 11 |
| Working form | Six-cylinder four-stroke turbocharged intercooled EFI engine |
| Ground specific pressure (Kpa) | 68 |
| Rotation speed (rpm) | 9.3 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 228.5 |
| Rod digging force (kN) | 176.5 |
| Maximum tractive force (kN) | 313.6 |
| Travel speed (km/h) | 3.0-4.8 |
| Main overflow set pressure (Mpa) | 33 |
| Rotary hydraulic motor type | Quantitative swash plate axial piston motor |
| Type of walking hydraulic motor | Variable swash plate axial piston motor |
| Maximum flow of main pump (l/min) | 2 x 288 |
| Traveling Hydraulic Circuit (Mpa) | 360 |
| Rotary Hydraulic Circuit (Mpa) | 290 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | 2× variable axial piston pump + gear pump |
| Working Hydraulic Circuit (Mpa) | 330 |
| Pilot Oil Circuit (MPa) | 40 |
| Bucket cylinders - Number × diameter × stroke (mm) | 150 x 1295 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 170 x 1760 |
| Boom cylinders - Number × diameter × stroke (mm) | 160 x 1500 |
| Fuel Tank (L) | 550 |
| Hydraulic Tank (L) | 210 |
| Engine Oil changes (L) | 33.5 |
| Coolant (L) | 50 |
| Hydraulic System (L) | 415 |
| Total transport length (mm) | 11240 |
| Total transport width (mm) | 3340 |
| Total transport height (mm) | 3570 |
| Full cab height (mm) | 3175 |
| Counterweight ground clearance (mm) | 1290 |
| Minimum ground clearance (mm) | 550 |
| Minimum turning radius of front working device (mm) | 4600 |
| Back end turning radius (mm) | 3415 |
| Onboard width (mm) | 2980 |
| Total track length (mm) | 5280 |
| Track gauge (mm) | 2740 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3340 |
| Track ground length (mm) | 4340 |
| Maximum digging radius (mm) | 11910 |
| Maximum digging depth (mm) | 7120 |
| Maximum excavation height (mm) | 10420 |
| Maximum unloading height (mm) | 7410 |
| Maximum vertical digging depth (mm) | 6220 |
| Bulldozer lift or depth (mm) | There is no |
| Dodging plate width × height (mm) | There is no |
| Maximum excavation radius of stop surface (mm) | 10680 |
| Maximum effective digging depth (mm) | 7360 |
