Product Description
Engineered with precision hydraulics delivering 144 l/min maximum flow, this 2018 JohnDeere E60 compact excavator demonstrates superior operational efficiency in demanding construction environments. The robust Yanmar 4TNV94L engine generates 35.3kW at 2000 RPM through a proven 4-cylinder, 3.054L displacement design, ensuring reliable performance across extended work cycles.
Built on JohnDeere's established E-series platform, this 6-ton machine combines exceptional digging capabilities with compact maneuverability. Key performance specifications include:
- Bucket digging force: 36.3 kN with 0.22 m³ capacity
- Working weight: 5,700 kg with optimized 33.4 kPa ground pressure
- Dual travel speeds: 2.6/4.5 km/h for versatile site navigation
- 400mm track plates providing enhanced stability
- 312mm minimum ground clearance for obstacle management
Currently positioned in Sichuan, China, this joint venture manufactured unit represents proven engineering excellence. The integrated hydraulic system maintains 100L capacity while the 109L fuel tank supports extended operational periods without frequent refueling interruptions.
| Specifications | Value |
|---|---|
| No. | 937458 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5700 |
| Bucket capacity (m³) | 0.22 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar 4TNV94L |
| Rated power (kw/rpm) | 35.3/2000 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.054 |
| Ground specific pressure (Kpa) | 33.4 |
| Bucket digging force (kN) | 36.3 |
| Rod digging force (kN) | 28 |
| Travel speed (km/h) | 2.6 / 4.5 |
| Maximum flow of main pump (l/min) | 144 |
| Fuel Tank (L) | 109 |
| Hydraulic System (L) | 100 |
| Minimum ground clearance (mm) | 312 |
| Track plate width (mm) | 400 |
| Number of sprockets (single side) (each) | 1 |
| Bulldozer lift or depth (mm) | 389 / 399 |
| Dodging plate width × height (mm) | 2020 x 411 |
