Product Description
Built for endurance and engineered in Japan, this 2021 Kobelco SK130 excavator demonstrates proven reliability with its robust 13-ton frame and powerful Mitsubishi D04FR engine. Operating at 74kW/2000rpm, this workhorse delivers consistent performance across demanding construction sites.
Key specifications include:
- Working weight: 12,800kg with 0.52m³ bucket capacity
- Maximum digging reach: 8,340mm with 5,520mm depth capability
- Bucket digging force: 90.1kN for tough material handling
- Fuel efficiency: 275L tank capacity for extended operation
- Compact transport dimensions: 7,790mm × 2,490mm × 2,710mm
With only three years of service, this SK130 represents exceptional value for contractors seeking dependable excavation equipment. Its 70% climbing ability and 11.5rpm rotation speed ensure versatility across varied terrain conditions. Currently located in Shaoxing, Zhejiang, this machine combines Japanese engineering excellence with practical field-tested durability.
| Specifications | Value |
|---|---|
| No. | 990767 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 12800 |
| Bucket capacity (m³) | 0.52 |
| Country of origin | Japan |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Mitsubishi D04FR |
| Rated power (kw/rpm) | 74/2000 |
| Rotation speed (rpm) | 11.5 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 90.1 |
| Travel speed (km/h) | 3.4/5.6 |
| Fuel Tank (L) | 275 |
| Hydraulic Tank (L) | 101 |
| Total transport length (mm) | 7790 |
| Total transport width (mm) | 2490 |
| Total transport height (mm) | 2710 |
| Full cab height (mm) | 2870 |
| Minimum ground clearance (mm) | 440 |
| Back end turning radius (mm) | 2190 |
| Onboard width (mm) | 2490 |
| Total track length (mm) | 3580 |
| Track gauge (mm) | 2870 |
| Track plate width (mm) | 500/600/700 |
| Maximum digging radius (mm) | 8340 |
| Maximum digging depth (mm) | 5520 |
| Maximum excavation height (mm) | 8500 |
| Maximum unloading height (mm) | 6090 |
| Maximum vertical digging depth (mm) | 4880 |
| Dodging plate width × height (mm) | 500 |
| Maximum excavation radius of stop surface (mm) | 8190 |
| Maximum effective digging depth (mm) | 5290 |
