Product Description
Built for precision and reliability, this 2021 Kobelco SK200 excavator delivers exceptional operator control with its advanced cabin design and superior visibility features. Operating at 20 tons with a robust Mitsubishi 6D34-TLU2D engine producing 110kW at 2000 RPM, this machine combines power with refined handling characteristics that experienced operators demand.
Key operational advantages include:
- Enhanced stability with optimized ground pressure distribution (35-45 KPa)
- Precise hydraulic control via double variable displacement axial piston pump system
- Superior digging performance: 143kN bucket force, 97.1kN arm force
- Comfortable operator environment with excellent sightlines and ergonomic controls
- Efficient fuel management with 340L tank capacity
- Versatile track configurations (600mm/800mm width options)
Currently located in Shaoxing, Zhejiang Province, this well-maintained excavator represents proven Japanese engineering with the handling precision that sets Kobelco apart in the 20-ton class. Water-cooled turbocharged engine ensures consistent performance across demanding job sites.
| Specifications | Value |
|---|---|
| No. | 989682 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 20000 |
| Bucket capacity (m³) | 0.8 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Mitsubishi 6D34-TLU2D |
| Rated power (kw/rpm) | 110/2000 |
| Cooling mode | water-cooling |
| Working form | Water-cooled, four-stroke, six-cylinder, direct injection, turbocharged, built-in intercooling |
| Ground specific pressure (Kpa) | 45; 35 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 143; Supercharged state: 157 |
| Rod digging force (kN) | 97.1; Supercharged state: 107 |
| Travel speed (km/h) | 1 speed: 4.0 2 speed :6.0 |
| Main overflow set pressure (Mpa) | 34.3; Supercharged state: 37.8 |
| Main pump type | Double variable displacement axial piston pump pilot gear pump |
| Fuel Tank (L) | 340 |
| Track plate width (mm) | 600; 800 |
