Product Description
Strengthen your fleet operations with this reliable 2016 Kobelco SK60-8 compact excavator, currently available in Shenzhen, Guangdong. Built for consistent performance in tight spaces, this 6-ton machine delivers 35.5kW of power through its proven Yanmar 4TNV94L engine, making it an ideal backup unit for contractors managing multiple job sites simultaneously.
Key operational specifications include:
- Maximum digging depth of 3,890mm with 6,200mm reach radius
- Compact transport dimensions (5,850 × 1,960 × 2,550mm) for easy mobilization
- Robust digging forces: 40.1kN bucket, 25.2kN arm
- Dual variable piston pump hydraulic system for responsive control
- 400mm track plates providing 32.7kPa ground pressure
Perfect for urban construction, utility work, and landscaping projects where space constraints demand precision. This unit's proven track record and manageable size make it an excellent addition to established fleets requiring dependable secondary equipment. Ready for immediate deployment across diverse applications.
| Specifications | Value |
|---|---|
| No. | 990102 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5610 |
| Bucket capacity (m³) | 0.22 |
| Rod length (mm) | 1660 |
| Country of origin | Chengdu |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar 4TNV94L |
| Rated power (kw/rpm) | 35.5/2400 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 21.7/1440 |
| Number of cylinders (PCS) | 4 |
| Working form | Direct injection |
| Ground specific pressure (Kpa) | 32.7 |
| Rotation speed (rpm) | 8.9 |
| Climbing ability (%) | 58% (30 degrees) |
| Bucket digging force (kN) | 40.1 |
| Rod digging force (kN) | 25.2 |
| Travel speed (km/h) | 4.2/2.5 |
| Main overflow set pressure (Mpa) | 23 |
| Maximum flow of main pump (l/min) | 2*57.1 |
| Main pump type | Variable piston pump *2+ gear pump *2 |
| Total transport length (mm) | 5850 |
| Total transport width (mm) | 1960 |
| Total transport height (mm) | 2550 |
| Full cab height (mm) | 2550 |
| Track plate width (mm) | 400 |
| Maximum digging radius (mm) | 6200 |
| Maximum digging depth (mm) | 3890 |
| Maximum excavation height (mm) | 5730 |
| Maximum unloading height (mm) | 4200 |
| Bulldozer lift or depth (mm) | 470/380 |
| Dodging plate width × height (mm) | 1960*345 |
