Product Description
Built for endurance and engineered for reliability, this 2013 Kobelco SK75 excavator delivers proven performance in the 7-ton class. Powered by a robust ISUZU AU4LE2X engine producing 41kW at 2200 RPM, this machine combines Japanese engineering excellence with practical operational capabilities.
Kobelco's reputation for durability makes this unit an intelligent investment in the used equipment market. With widespread parts availability and strong resale values, Kobelco excavators maintain their worth while minimizing downtime costs. This SK75 features a maximum digging depth of 4,160mm and reach of 6,460mm, supported by a sophisticated hydraulic system operating at 29.4 MPa working pressure.
- 7-ton working weight with compact 2,630mm transport height
- Dual-speed travel system (2.8/5.3 km/h) for versatility
- 120L fuel capacity for extended operation
- Water-cooled 4-cylinder engine with 2.179L displacement
- Currently located in Hubei, China
Kobelco's established dealer network ensures ongoing support, making this SK75 a secure choice for contractors seeking dependable used equipment with predictable maintenance costs.
| Specifications | Value |
|---|---|
| No. | 959374 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 7000(approx) |
| Country of origin | Chengdu |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | ISUZU AU4LE2X |
| Rated power (kw/rpm) | 41/2200 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 85 x 96 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 2.179 |
| Rotary hydraulic motor type | Axial piston motor |
| Traveling Hydraulic Circuit (Mpa) | 27.5 |
| Rotary Hydraulic Circuit (Mpa) | 14.5 |
| Control Hydraulic Circuit (Mpa) | 3.5 |
| Main pump type | Double variable displacement axial piston pump + pilot gear pump |
| Working Hydraulic Circuit (Mpa) | 29.4 |
| Fuel Tank (L) | 120 |
| Hydraulic Tank (L) | 72 |
| Engine Oil changes (L) | 11 |
| Coolant (L) | 8.5 |
| Hydraulic System (L) | 120 |
| Total transport height (mm) | 2630 |
| Full cab height (mm) | 2630 |
| Minimum turning radius of front working device (mm) | 1760 |
| Back end turning radius (mm) | 1290 |
| Maximum digging radius (mm) | 6460 |
| Maximum digging depth (mm) | 4160 |
| Maximum excavation height (mm) | 7390 |
| Maximum unloading height (mm) | 5330 |
| Maximum vertical digging depth (mm) | 3450 |
| Maximum excavation radius of stop surface (mm) | 6300 |
| Maximum effective digging depth (mm) | 3800 |
| Travel speed (km/h) | 2.8/5.3 |
