Product Description
Engineered with precision, this 2013 Sany SY215W delivers exceptional hydraulic performance through its advanced 21.5-ton platform. The robust Isuzu 4HK1 engine generates 128.4kW at 2000 RPM, providing reliable power for demanding excavation tasks. With 670 N·m maximum torque and a substantial 5.193L displacement, this machine maintains consistent performance across varied operating conditions.
Superior hydraulic capabilities define this model's technical excellence:
- Bucket digging force: 117.5 kN for efficient material handling
- Rod digging force: 102.9 kN ensuring precise control
- 0.93 m³ bucket capacity optimized for productivity
- 35° climbing ability for challenging terrain navigation
- 11.9 RPM rotation speed enabling smooth operation cycles
Built for extended operation with a 400L fuel tank and 230L hydraulic reservoir, this wheeled excavator combines mobility with power. Currently located in Foshan, Guangdong, this machine represents proven Sany engineering quality backed by comprehensive technical specifications that meet industrial excavation standards.
| Specifications | Value |
|---|---|
| No. | 987945 |
| Tonnage (tons) | 21.5 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 0.93 |
| power | Fuel oil |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Isuzu 4HK1 |
| Rated power (kw/rpm) | 128.4/2000 |
| Total displacement (L) | 5.193 |
| Maximum torque (N.m) | 670/1600 |
| Forward speed (Km/h) | 38/10 |
| Rotation speed (rpm) | 11.9 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 117.5 |
| Rod digging force (kN) | 102.9 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 230 |
| Engine Oil changes (L) | 20 |
