Product Description
Built for demanding construction environments, this 2015 Sany SY265C delivers reliable 26-ton performance with proven Mitsubishi D06FRC engine technology. Operating at 147kW rated power, the machine provides consistent hydraulic flow for precise material handling and excavation tasks.
Operator-focused design features enhance productivity through improved cabin visibility and intuitive control response. The hydraulic system generates 175kN bucket digging force with smooth 10.6 rpm rotation speed, enabling accurate positioning in confined work areas. Ground-level stability remains optimal with 52.5 Kpa ground pressure distribution across 600mm track plates.
- 26,500kg working weight with 1.3m³ bucket capacity
- 10,225mm maximum digging radius for extended reach
- 6,705mm maximum digging depth capability
- 475L fuel tank for extended operation cycles
- Water-cooled engine with 750 N.m maximum torque
Currently located in Shandong Heze, this machine combines proven Chinese manufacturing with Japanese engine reliability for consistent jobsite performance.
| Specifications | Value |
|---|---|
| No. | 990754 |
| Tonnage (tons) | 26 |
| Working weight (kg) | 26500 |
| Bucket capacity (m³) | 1.3 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Mitsubishi D06FRC |
| Rated power (kw/rpm) | 147/2100 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 750/1350 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.373 |
| Ground specific pressure (Kpa) | 52.5 |
| Rotation speed (rpm) | 10.6 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 175 |
| Rod digging force (kN) | 120 |
| Travel speed (km/h) | 5.8/3.7 |
| Fuel Tank (L) | 475 |
| Hydraulic Tank (L) | 277 |
| Engine Oil changes (L) | 29 |
| Total transport length (mm) | 10290 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3255 |
| Minimum ground clearance (mm) | 470 |
| Back end turning radius (mm) | 3105 |
| Total track length (mm) | 4635 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 3830 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 9 |
| Number of track plates (single side) (PCS) | 51 |
| Maximum digging radius (mm) | 10225 |
| Maximum digging depth (mm) | 6705 |
| Maximum excavation height (mm) | 9745 |
| Maximum unloading height (mm) | 6715 |
