Product Description
Powered by a robust GH-6HK1XKSC engine delivering 212kW at 2000rpm, this 2018 Sany SY365H represents proven hydraulic excavation technology. With 36 tons of working weight and advanced water-cooling systems, this machine demonstrates the engineering excellence that defines Sany's heavy equipment manufacturing standards.
Key performance specifications include:
- Maximum digging radius of 10,780mm with 7,050mm depth capability
- Bucket digging force reaching 235kN for demanding excavation tasks
- 1.6-2.32m³ bucket capacity range accommodating diverse material handling requirements
- 690L fuel tank capacity supporting extended operational periods
- 70% climbing ability (35°) for challenging terrain navigation
Located in Foshan, Guangdong, this hydraulic excavator features traditional power systems with maximum torque output of 1,080N.m at 1500rpm. The machine's 600mm track plate width and 65kPa ground pressure distribution ensure optimal stability across varied jobsite conditions. Professional maintenance records available upon inspection.
| Specifications | Value |
|---|---|
| No. | 987610 |
| Tonnage (tons) | 36 |
| Working weight (kg) | 36000 |
| Bucket capacity (m³) | 1.6~2.32 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | GH-6HK1XKSC |
| Rated power (kw/rpm) | 212/2000 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 1080/1500 |
| Displacement (L) | 7.79 |
| Ground specific pressure (Kpa) | 65 |
| Rotation speed (rpm) | 9.5 |
| Climbing ability (%) | 70% (35°) |
| Bucket digging force (kN) | 235 |
| Rod digging force (kN) | 180 |
| Travel speed (km/h) | 5.5/3.5 |
| Fuel Tank (L) | 690 |
| Hydraulic Tank (L) | 380 |
| Engine Oil changes (L) | 36 |
| Total transport length (mm) | 11530 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3545 |
| Full cab height (mm) | 3320 |
| Minimum ground clearance (mm) | 550 |
| Minimum turning radius of front working device (mm) | 4495 |
| Back end turning radius (mm) | 3560 |
| Onboard width (mm) | 3150 |
| Total track length (mm) | 5065 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Track ground length (mm) | 4140 |
| Maximum height at minimum turning radius (mm) | 8600 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 9 |
| Number of track plates (single side) (PCS) | 49 |
| Maximum digging radius (mm) | 10780 |
| Maximum digging depth (mm) | 7050 |
| Maximum excavation height (mm) | 9890 |
| Maximum unloading height (mm) | 6920 |
| Maximum vertical digging depth (mm) | 3970 |
