Product Description
Engineered with precision hydraulics delivering 34.3 MPa working pressure, this 2021 Sumitomo SH130-6 excavator represents proven Japanese engineering excellence in the 13-ton class. Powered by a robust 70.9kW engine at 2000 RPM with 2.999L displacement, it combines reliable performance with fuel efficiency from its 260L tank capacity.
Advanced hydraulic systems generate exceptional digging forces of 91kN bucket and 62kN rod capacity, while the variable capacity piston pump ensures smooth operation across demanding applications. With an impressive 8.31m maximum digging radius and 5.54m depth capability, this machine tackles substantial excavation projects with authority.
- 13-ton working weight with 0.5-0.55m³ bucket capacity
- 4600mm boom and 2500mm rod configuration for optimal reach
- 70% climbing ability with 5.6/3.4 km/h travel speeds
- Compact 7620mm transport length for site mobility
- Located in Zhejiang Shaoxing for immediate inspection
Built on Sumitomo's SH130-6 platform, this excavator delivers the engineering reliability and operational efficiency that construction professionals demand for medium-scale earthmoving operations.
| Specifications | Value |
|---|---|
| No. | 989329 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 12700 |
| Bucket capacity (m³) | 0.5-0.55 |
| Boom length (mm) | 4600 |
| Rod length (mm) | 2500 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | |
| Rated power (kw/rpm) | 70.9/2000 |
| Displacement (L) | 2.999 |
| Rotation speed (rpm) | 14.1 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 91 |
| Rod digging force (kN) | 62 |
| Travel speed (km/h) | 5.6/3.4 |
| Main overflow set pressure (Mpa) | 34.3/36.3 |
| Rotary hydraulic motor type | |
| Type of walking hydraulic motor | Variable capacity piston pump |
| Main pump type | |
| Working Hydraulic Circuit (Mpa) | 34.3/36.3 |
| Fuel Tank (L) | 260 |
| Hydraulic Tank (L) | 82 |
| Hydraulic System (L) | 157 |
| Total transport length (mm) | 7620 |
| Total transport width (mm) | 2540 |
| Total transport height (mm) | 2820 |
| Counterweight ground clearance (mm) | 890 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 2340 |
| Back end turning radius (mm) | 2130 |
| Total track length (mm) | 3500 |
| Track plate width (mm) | 500 |
| Total track width (mm) | 2490 |
| Maximum digging radius (mm) | 8310 |
| Maximum digging depth (mm) | 5540 |
| Maximum excavation height (mm) | 8770 |
| Maximum unloading height (mm) | 6390 |
| Maximum vertical digging depth (mm) | 4590 |
