Product Description
Built for endurance and engineered to deliver, this 2016 Sumitomo SH80-6 excavator demonstrates exceptional longevity with nearly a decade of proven performance. Operating at 8 tons with a robust 7,460kg working weight, this machine combines the reliability of Isuzu AU-4LE2X engine technology with Sumitomo's renowned build quality.
Key performance specifications showcase its industrial capabilities:
- 40kW rated power at 2000 RPM for consistent operation
- 0.38m³ bucket capacity with 56.4kN digging force
- 6,460mm maximum digging radius for versatile reach
- 4,050mm maximum digging depth for deep excavation work
- 120L fuel tank capacity for extended operational periods
Currently located in Shenzhen, Guangdong, this proven workhorse represents solid value for contractors seeking dependable equipment. With its compact 2,320mm transport width and established track record, this excavator continues to demonstrate why Sumitomo machines maintain their reputation for durability in demanding construction environments.
| Specifications | Value |
|---|---|
| No. | 988954 |
| Tonnage (tons) | 8 |
| Working weight (kg) | 7460 |
| Bucket capacity (m³) | 0.38 |
| Rod length (mm) | 1690 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Isuzu AU-4LE2X |
| Rated power (kw/rpm) | 40/2000 |
| Displacement (L) | 2.179 |
| Rotation speed (rpm) | 9.9 |
| Climbing ability (%) | |
| Bucket digging force (kN) | 56.4 |
| Rod digging force (kN) | 39.3 |
| Travel speed (km/h) | 5.1/3.2 |
| Main overflow set pressure (Mpa) | 29.4 |
| Type of walking hydraulic motor | |
| Main pump type | |
| Working Hydraulic Circuit (Mpa) | 29.4 |
| Fuel Tank (L) | 120 |
| Hydraulic Tank (L) | 51 |
| Hydraulic System (L) | 96 |
| Total transport length (mm) | 6090 |
| Total transport width (mm) | 2320 |
| Total transport height (mm) | 2750 |
| Counterweight ground clearance (mm) | 750 |
| Minimum turning radius of front working device (mm) | 1980 |
| Back end turning radius (mm) | 1750 |
| Total track length (mm) | 2845 |
| Track plate width (mm) | 450 |
| Total track width (mm) | 2320 |
| Track ground length (mm) | 2210 |
| Maximum digging radius (mm) | 6460 |
| Maximum digging depth (mm) | 4050 |
| Maximum excavation height (mm) | 6950 |
| Maximum unloading height (mm) | 4890 |
