Product Description
Built for precision work in tight spaces, this 2021 Volvo EC20 compact excavator delivers reliable performance with its Mitsubishi L3E engine producing 14kW at 2200 rpm. Currently located in Luzhou, Sichuan, this 1.78-ton machine combines maneuverability with robust digging capabilities.
Engineered for immediate deployment on construction sites, the EC20 features a 0.05m³ bucket capacity and reaches maximum digging depths of 2.57 meters. Its compact 3.78m transport length allows easy movement between job sites while maintaining professional-grade hydraulic performance with 21 MPa system pressure.
- Maximum excavation height: 3.75m for versatile reach
- 4.01m excavation radius handles diverse digging tasks
- Low ground pressure (28.4 kPa) protects finished surfaces
- 21-liter fuel tank supports extended operation cycles
- 1.16m rear swing radius enables work in confined areas
Ready for grading, trenching, and demolition work, this Volvo excavator combines proven reliability with the precision control operators demand for professional results.
| Specifications | Value |
|---|---|
| No. | 990543 |
| Tonnage (tons) | 2 |
| Working weight (kg) | 1780 |
| Bucket capacity (m³) | 0.05 |
| Boom length (mm) | 1900 |
| Rod length (mm) | 1050 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Mitsubishi L3E |
| Rated power (kw/rpm) | 14/2200 |
| Maximum torque (N.m) | 54/1850 |
| Number of cylinders (PCS) | 3 |
| Displacement (L) | 0.95 |
| Ground specific pressure (Kpa) | 28.4 |
| Rotation speed (rpm) | 10 |
| Travel speed (km/h) | 4.7 |
| Main overflow set pressure (Mpa) | 21 |
| Maximum flow of main pump (l/min) | 43 |
| Fuel Tank (L) | 21 |
| Engine Oil changes (L) | 3.6 |
| Coolant (L) | 4.5 |
| Hydraulic System (L) | 23 |
| Total transport length (mm) | 3780 |
| Total transport width (mm) | 1200 |
| Total transport height (mm) | 2270 |
| Full cab height (mm) | 2270 |
| Counterweight ground clearance (mm) | 470 |
| Back end turning radius (mm) | 1160 |
| Track gauge (mm) | 950 |
| Track plate width (mm) | 250 |
| Track ground length (mm) | 1240 |
| Maximum digging depth (mm) | 2570 |
| Maximum excavation height (mm) | 3750 |
| Maximum unloading height (mm) | 2670 |
| Maximum vertical digging depth (mm) | 1580 |
| Maximum excavation radius of stop surface (mm) | 4010 |
