Product Description
Expand your fleet capacity with this reliable 2021 XCMG XE18 mini excavator, strategically positioned in Hangzhou for immediate deployment. Built around the proven Yanmar 3TNV82A engine delivering 16.5kW at 2200 RPM, this compact 1.78-ton workhorse maintains consistent performance across demanding jobsites.
Engineered for versatility, the XE18 combines a 3915mm maximum digging radius with precise 0.044m³ bucket capacity, making it ideal for confined spaces and detail work. Dual variable pumps ensure responsive hydraulic control, while the water-cooled 3-cylinder engine provides dependable power for extended operations.
- Maximum digging depth: 2285mm with 13.9kN bucket force
- Compact transport dimensions: 3760 × 1300 × 2405mm
- 30° climbing capability with 25.3kPa ground pressure
- Standard hydraulic crushing pipeline ready
- Proven Japanese hydraulic components
Perfect as a backup unit or fleet expansion, this XE18 delivers the reliability contractors demand without the premium of new equipment pricing. Ready for immediate integration into existing operations.
| Specifications | Value |
|---|---|
| No. | 988319 |
| Tonnage (tons) | 2 |
| Working weight (kg) | 1780 |
| Bucket capacity (m³) | 0.044 |
| Boom length (mm) | 1690 |
| Rod length (mm) | 1100 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Yanmar Yanmar 3TNV82A |
| Rated power (kw/rpm) | 16.5/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 3 |
| Displacement (L) | 1.33 |
| Ground specific pressure (Kpa) | 25.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 30 ° |
| Bucket digging force (kN) | 13.9 |
| Rod digging force (kN) | 8.8 |
| Travel speed (km/h) | 4.4/2.4 |
| Main overflow set pressure (Mpa) | 24 |
| Rotary hydraulic motor type | Plunger hydraulic motor |
| Type of walking hydraulic motor | Plunger hydraulic motor |
| Maximum flow of main pump (l/min) | 2*19.8+14.1 |
| Traveling Hydraulic Circuit (Mpa) | 21 |
| Rotary Hydraulic Circuit (Mpa) | 18 |
| Hydraulic crushing pipeline is standard | is |
| Main pump type | Japan non Fukoshi variable pump ×2+ gear pump ×1 |
| Pilot Oil Circuit (MPa) | 3.3 |
| Fuel Tank (L) | 20 |
| Hydraulic Tank (L) | 29 |
| Engine Oil changes (L) | 5.5 |
| Total transport length (mm) | 3760 |
| Total transport width (mm) | 1300 |
| Total transport height (mm) | 2405 |
| Counterweight ground clearance (mm) | 509 |
| Minimum ground clearance (mm) | 180 |
| Minimum turning radius of front working device (mm) | 1675 |
| Back end turning radius (mm) | 1190 |
| Track gauge (mm) | 1070 |
| Track plate width (mm) | 230 |
| Track ground length (mm) | 1217 |
| Maximum digging radius (mm) | 3915 |
| Maximum digging depth (mm) | 2285 |
| Maximum excavation height (mm) | 2655 |
| Maximum unloading height (mm) | 2515 |
| Maximum vertical digging depth (mm) | 1485 |
| Dodging plate width × height (mm) | 1300 x 235 |
