Product Description
Built for precision work in tight spaces, this 2022 XCMG XE18 mini excavator delivers reliable performance with its Yanmar 3TNV82A engine producing 16.5kW at 2200 RPM. Operating at just 1.78 tons, the machine maintains excellent stability while providing operators with superior maneuverability in confined job sites.
Key operational advantages include:
- Compact 1300mm transport width enables access through standard gates
- Maximum digging depth of 2285mm with 3915mm reach radius
- Dual-speed travel system (4.4/2.4 km/h) for efficient site navigation
- 30-degree climbing capability handles challenging terrain
- 11 RPM rotation speed ensures smooth positioning
Hydraulic system features dual variable pumps with 24 MPa main pressure, delivering 13.9kN bucket digging force and 8.8kN rod force. Water-cooled engine with 20L fuel capacity provides extended operating periods. Standard hydraulic crushing pipeline preparation adds versatility for attachment options. Located in Hunan province, this well-maintained unit offers proven XCMG engineering at an attractive price point.
| Specifications | Value |
|---|---|
| No. | 988788 |
| Tonnage (tons) | 2 |
| Working weight (kg) | 1780 |
| Bucket capacity (m³) | 0.044 |
| Boom length (mm) | 1690 |
| Rod length (mm) | 1100 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Yanmar Yanmar 3TNV82A |
| Rated power (kw/rpm) | 16.5/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 3 |
| Displacement (L) | 1.33 |
| Ground specific pressure (Kpa) | 25.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 30 ° |
| Bucket digging force (kN) | 13.9 |
| Rod digging force (kN) | 8.8 |
| Travel speed (km/h) | 4.4/2.4 |
| Main overflow set pressure (Mpa) | 24 |
| Rotary hydraulic motor type | Plunger hydraulic motor |
| Type of walking hydraulic motor | Plunger hydraulic motor |
| Maximum flow of main pump (l/min) | 2*19.8+14.1 |
| Traveling Hydraulic Circuit (Mpa) | 21 |
| Rotary Hydraulic Circuit (Mpa) | 18 |
| Hydraulic crushing pipeline is standard | is |
| Main pump type | Japan non Fukoshi variable pump ×2+ gear pump ×1 |
| Pilot Oil Circuit (MPa) | 3.3 |
| Fuel Tank (L) | 20 |
| Hydraulic Tank (L) | 29 |
| Engine Oil changes (L) | 5.5 |
| Total transport length (mm) | 3760 |
| Total transport width (mm) | 1300 |
| Total transport height (mm) | 2405 |
| Counterweight ground clearance (mm) | 509 |
| Minimum ground clearance (mm) | 180 |
| Minimum turning radius of front working device (mm) | 1675 |
| Back end turning radius (mm) | 1190 |
| Track gauge (mm) | 1070 |
| Track plate width (mm) | 230 |
| Track ground length (mm) | 1217 |
| Maximum digging radius (mm) | 3915 |
| Maximum digging depth (mm) | 2285 |
| Maximum excavation height (mm) | 2655 |
| Maximum unloading height (mm) | 2515 |
| Maximum vertical digging depth (mm) | 1485 |
| Dodging plate width × height (mm) | 1300 x 235 |
