Product Description
Skip the factory lead times with this ready-to-deploy 2019 XCMG XE60 excavator, currently available in 安徽 for immediate delivery to your construction site. Operating at 6 tons with a robust Yanmar 4TNV94L engine delivering 39.8kW of reliable power, this compact workhorse combines proven Chinese engineering with exceptional maneuverability in tight spaces.
Built for versatility, the XE60 features variable bucket capacity from 0.09-0.23 m³, maximum digging depth of 3,830mm, and impressive reach extending to 6,130mm. With 42.5kN bucket digging force and dual-speed travel capabilities (4.2/2.2 km/h), this machine handles demanding excavation tasks while maintaining fuel efficiency through its 110L tank capacity.
- Immediate availability from 安徽 - no waiting for new equipment
- Compact 1,880mm transport width fits standard trailers
- Rexroth hydraulic system ensures consistent performance
- 35° climbing ability tackles challenging terrain
- Water-cooled 4-cylinder engine for extended operation
Fast deployment means faster project completion. Contact us today for immediate shipping arrangements.
| Specifications | Value |
|---|---|
| No. | 989001 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5960 |
| Bucket capacity (m³) | 0.09-0.23 |
| Boom length (mm) | 3000 |
| Rod length (mm) | 1600 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Yanmar 4TNV94L |
| Rated power (kw/rpm) | 39.8/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.054 |
| Ground specific pressure (Kpa) | 32.1 |
| Rotation speed (rpm) | 9.5 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 42.5 |
| Rod digging force (kN) | 28.5 |
| Travel speed (km/h) | 4.2/2.2 |
| Main overflow set pressure (Mpa) | 22 |
| Maximum flow of main pump (l/min) | 2*60.5+40.3+9.9 |
| Traveling Hydraulic Circuit (Mpa) | 22 |
| Rotary Hydraulic Circuit (Mpa) | 23 |
| Hydraulic crushing pipeline is standard | is |
| Main pump type | Rexroth |
| Pilot Oil Circuit (MPa) | 2.9 |
| Fuel Tank (L) | 110 |
| Hydraulic Tank (L) | 85 |
| Engine Oil changes (L) | 5.3 |
| Total transport length (mm) | 5850 |
| Total transport width (mm) | 1880/1920 |
| Total transport height (mm) | 2585 |
| Counterweight ground clearance (mm) | 694 |
| Minimum ground clearance (mm) | 369 |
| Minimum turning radius of front working device (mm) | 2450 |
| Back end turning radius (mm) | 1650 |
| Track gauge (mm) | 1480/1500 |
| Track plate width (mm) | 400 |
| Track ground length (mm) | 1985/1990 |
| Maximum digging radius (mm) | 6130 |
| Maximum digging depth (mm) | 3830 |
| Maximum excavation height (mm) | 5630 |
| Maximum unloading height (mm) | 3945 |
| Maximum vertical digging depth (mm) | 2680 |
| Dodging plate width × height (mm) | 1880*365/1920*340 |
