2016 Caterpillar 326DL
Product Description
Maximize your construction budget with this proven 2016 Caterpillar 326DL excavator, delivering professional-grade performance at a fraction of new equipment costs. Built in Xuzhou with Cat's renowned C7 ACERT engine producing 140kW, this 26-ton workhorse combines reliability with exceptional value.
Key performance specifications include:
- 1.35/1.57 m³ bucket capacity for versatile material handling
- 6.74m maximum digging depth with 174kN bucket digging force
- 10.03m maximum excavation radius for extended reach capabilities
- Water-cooled 7.2L engine with 520L fuel capacity for extended operation
- Advanced hydraulic system with 235 l/min main pump flow
Currently located in Maoming, Guangdong, this machine offers the durability and productivity Caterpillar is known for without the premium price tag. Smart contractors recognize that quality used equipment like this 326DL provides immediate ROI while maintaining the performance standards required for demanding jobsites. Invest wisely in proven machinery that works as hard as you do.
| Specifications | Value |
|---|---|
| No. | 983223 |
| Tonnage (tons) | 26 |
| Working weight (kg) | 25560 |
| Bucket capacity (m³) | 1.35/1.57 |
| Boom length (mm) | 5300/5900 |
| Rod length (mm) | 2000/2500/2950 |
| Country of origin | Xuzhou, Jiangsu |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar C7 ACERT |
| Rated power (kw/rpm) | 140 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 110 x 127 |
| Displacement (L) | 7.2 |
| Rotation speed (rpm) | 9.6 |
| Bucket digging force (kN) | 174 |
| Rod digging force (kN) | 122 |
| Maximum tractive force (kN) | 227 |
| Travel speed (km/h) | 5.5 |
| Turning torque (Nm) | 73.4 |
| Main overflow set pressure (Mpa) | 35 |
| Rotary hydraulic motor type | 24.5 |
| Type of walking hydraulic motor | 35 |
| Maximum flow of main pump (l/min) | 235 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1 x 150 x 1156 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1 x 140 x 1660 |
| Boom cylinders - Number × diameter × stroke (mm) | 2 x 135 x 1305 |
| Fuel Tank (L) | 520 |
| Hydraulic Tank (L) | 145 |
| Engine Oil changes (L) | 30 |
| Coolant (L) | 30 |
| Hydraulic System (L) | 300 |
| Total transport length (mm) | 10060 |
| Total transport width (mm) | 3390 |
| Total transport height (mm) | 3170 |
| Full cab height (mm) | 2980 |
| Counterweight ground clearance (mm) | 1060 |
| Minimum ground clearance (mm) | 470 |
| Back end turning radius (mm) | 2940 |
| Total track length (mm) | 4630 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3390 |
| Maximum digging depth (mm) | 6740 |
| Maximum excavation height (mm) | 9660 |
| Maximum unloading height (mm) | 6700 |
| Maximum vertical digging depth (mm) | 5830 |
| Maximum excavation radius of stop surface (mm) | 10030 |
| Maximum effective digging depth (mm) | 6560 |
Overview
No.983223
Brand Name：
CaterpillarModel Number：
326DLYear：
2016
Location：
Guangdong China
