Product Description
Strengthen your fleet capacity with this reliable 2016 Doosan DL507-9C wheel loader, strategically positioned in Jiangxi, China for immediate deployment. Built for demanding construction and material handling operations, this machine delivers consistent performance when your primary equipment needs support or maintenance downtime threatens project schedules.
Key operational specifications include:
- 162kW power output at 2000 RPM with 980 N.m maximum torque
- 5-ton rated load capacity with 2.7-5.0m³ bucket range
- 16.4kN digging force and 16.8kN maximum tractive force
- 37.7 km/h maximum speed for efficient site mobility
- 330L fuel tank and 250L hydraulic tank for extended operation
- Compact 6.52m turning radius despite 16,800kg operating weight
With proven Doosan engineering and comprehensive specifications including 3.21m maximum unloading height, this loader integrates seamlessly into existing fleet operations. Smart contractors maintain backup capacity to avoid costly project delays—this unit provides that critical operational insurance while delivering the reliability your business demands.
| Specifications | Value |
|---|---|
| No. | 963169 |
| Rated power (kw/rpm) | 162 / 2000 |
| Maximum torque (N.m) | 980 |
| Bucket capacity (m³) | 2.7~5.0 |
| Rated load (tons) | |
| Rated load (kg) | 5000 |
| Digging force (lifting force) (kN) | 16.4 |
| Machine operating weight (kg) | 16800 |
| Max - Unloading height (mm) | 3210 |
| Unloading distance (mm) | 1170 |
| Maximum tractive force (kN) | 16.8 |
| Fuel Tank (L) | 330 |
| Hydraulic Tank (L) | 250 |
| Turning radius - Outside of bucket (mm) | 6520 |
| Maximum speed (km/h) | 37.7 |
| Machine length (mm) | 8000 |
| Machine width (mm) | 2992 |
| Machine height (mm) | 3450 |
