Product Description
Featuring a robust Yanmar 4TNV98 VDB24 engine, this 2016 Doosan DX80 excavator delivers 41.4 kW of power at 2100 rpm, ensuring reliable performance for a variety of tasks. With an 8-ton working weight and a bucket capacity ranging from 0.30 to 0.32 m³, it is designed for efficiency and versatility.
- Equipped with a backhoe bucket, the DX80 provides a maximum digging force of 56 kN, making it ideal for tough excavation jobs.
- The full cab height of 2,690 mm offers excellent visibility, enhancing operator comfort and safety.
- With a ground specific pressure of 37 Kpa and a climbing ability of 30%, this excavator handles uneven terrain with ease and stability.
- Travel speeds of 4.9 km/h and 3.1 km/h ensure that the machine can navigate sites efficiently, whether on flat or inclined surfaces.
Located in Hebei, China, this used Doosan DX80 is ready to meet your construction needs with its durable design and operator-focused features.
| Specifications | Value |
|---|---|
| No. | 964397 |
| Tonnage (tons) | 8 |
| Working weight (kg) | 7900 |
| Bucket capacity (m³) | 0.30 ~ 0.32 |
| Country of origin | Yantai, China |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar 4TNV98 VDB24 |
| Rated power (kw/rpm) | 41.4 / 2100 |
| Cylinder diameter × stroke (mm) | 98 x 110 |
| Number of cylinders (PCS) | 4 |
| Working form | 4-stroke, water-cooled, direct injection; Naturally aspirated, air-cooled |
| Ground specific pressure (Kpa) | 37 |
| Rotation speed (rpm) | 11.5 |
| Climbing ability (%) | 30 ° |
| Bucket digging force (kN) | 56 |
| Rod digging force (kN) | 41 |
| Maximum tractive force (kN) | 63 |
| Travel speed (km/h) | 4.9 / 3.1 |
| Turning torque (Nm) | 24.2 |
| Maximum flow of main pump (l/min) | 75.6 * 2 + 18.7 |
| Traveling Hydraulic Circuit (Mpa) | 28 |
| Working Hydraulic Circuit (Mpa) | 28 |
| Fuel Tank (L) | 145 |
| Total transport length (mm) | 6000 |
| Total transport width (mm) | 2290 |
| Total transport height (mm) | 2685 |
| Full cab height (mm) | 2,690 |
| Counterweight ground clearance (mm) | 825 |
| Back end turning radius (mm) | 1800 |
| Onboard width (mm) | 2,200 |
| Total track length (mm) | 2750 |
| Track gauge (mm) | 1,770 |
| Track plate width (mm) | 450 |
| Total track width (mm) | 2,220 |
| Maximum digging radius (mm) | 6350 |
| Maximum digging depth (mm) | 4165 |
| Maximum excavation height (mm) | 7120 |
| Maximum unloading height (mm) | 5115 |
| Maximum vertical digging depth (mm) | 3328 |
| Dodging plate width × height (mm) | 2200 x 418 |
