Product Description
Engineered with precision hydraulics delivering 126 L/min maximum flow, this 2016 Hitachi ZX80 combines Japanese manufacturing excellence with proven Isuzu CC-4JG1 engine technology. Rated at 39kW/2100rpm with 3.1L displacement, the powerplant drives an 8-ton platform designed for demanding excavation operations.
Key performance specifications include:
- Maximum digging depth: 4,170mm with 6,170mm excavation radius
- Hydraulic system capacity: 100L supporting consistent operation cycles
- Ground pressure optimization: 25kPa minimizing surface damage
- Transport dimensions: 6,080 x 2,200 x 2,600mm for efficient logistics
Built on Hitachi's ZX series foundation, this excavator features a 0.28m³ bucket capacity with 7,215kg working weight providing optimal balance between mobility and productivity. Located in Zhejiang Shaoxing, the machine represents proven Japanese engineering adapted for intensive construction and infrastructure projects requiring reliable hydraulic performance and fuel efficiency.
| Specifications | Value |
|---|---|
| No. | 988655 |
| Tonnage (tons) | 8 |
| Working weight (kg) | 7215 |
| Bucket capacity (m³) | 0.28 |
| Boom length (mm) | 3720 |
| Rod length (mm) | 1620 |
| Country of origin | Japan |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Isuzu CC-4JG1 |
| Rated power (kw/rpm) | 39/2100 |
| Displacement (L) | 3.1 |
| Ground specific pressure (Kpa) | 25 |
| Rotation speed (rpm) | 11.3 |
| Travel speed (km/h) | 5 |
| Maximum flow of main pump (l/min) | 126 |
| Fuel Tank (L) | 135 |
| Engine Oil changes (L) | 12 |
| Coolant (L) | 9.5 |
| Hydraulic System (L) | 100 |
| Total transport length (mm) | 6080 |
| Total transport width (mm) | 2200 |
| Total transport height (mm) | 2600 |
| Full cab height (mm) | 2600 |
| Counterweight ground clearance (mm) | 760 |
| Minimum ground clearance (mm) | 360 |
| Back end turning radius (mm) | 750 |
| Track gauge (mm) | 1600 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2200 |
| Track ground length (mm) | 2140 |
| Maximum digging depth (mm) | 4170 |
| Maximum excavation height (mm) | 7150 |
| Maximum unloading height (mm) | 5060 |
| Maximum vertical digging depth (mm) | 3730 |
| Maximum excavation radius of stop surface (mm) | 6170 |
