Product Description
Maximize your construction budget with this proven 2014 Sany SY235C-9 excavator. Operating at 23 tons with a robust ISUZU 6BG1 engine delivering 128.5kW of power, this machine delivers professional-grade performance at a fraction of new equipment costs.
Built for demanding jobsites, the SY235C-9 features impressive digging capabilities with 175kN bucket force and 10.15m maximum reach. Its 1.1m³ bucket capacity and 70% climbing ability handle diverse terrain challenges efficiently. The four-stroke, six-cylinder turbocharged engine ensures reliable operation while maintaining fuel economy.
- 23-ton operating weight with 24,200kg working capacity
- Maximum digging depth: 6.785m
- Travel speeds: 5.5/3.5 km/h for optimal mobility
- Compact transport dimensions: 9.92m × 2.98m × 3.55m
- Located in Zhejiang Shaoxing for convenient inspection
Smart buyers recognize quality used equipment delivers identical productivity at substantial savings. This SY235C-9 represents proven Chinese engineering with established parts availability and service support nationwide.
| Specifications | Value |
|---|---|
| No. | 987652 |
| Tonnage (tons) | 23 |
| Working weight (kg) | 24200 |
| Bucket capacity (m³) | 1.1 (Optional 1.1 to 1.2) |
| Country of origin | Shanghai |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | ISUZU 6BG1 |
| Rated power (kw/rpm) | 128.5/2100 |
| Number of cylinders (PCS) | 6-cylinder |
| Working form | Four-stroke, six-cylinder turbocharged direct injection engine |
| Ground specific pressure (Kpa) | 47.6 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 70% / 35 ° |
| Bucket digging force (kN) | 175 |
| Rod digging force (kN) | 122 |
| Travel speed (km/h) | 5.5/3.5 |
| Total transport length (mm) | 9920 |
| Total transport width (mm) | 2980 |
| Total transport height (mm) | 3550 |
| Full cab height (mm) | 2990 |
| Minimum ground clearance (mm) | 440 |
| Minimum turning radius of front working device (mm) | 3800 |
| Back end turning radius (mm) | 2890 |
| Onboard width (mm) | 2710 |
| Total track length (mm) | 4445 |
| Track gauge (mm) | 2380 |
| Track plate width (mm) | 600 (800/700 optional) |
| Total track width (mm) | 2980 |
| Track ground length (mm) | 3640 |
| Maximum height at minimum turning radius (mm) | 7940 |
| Maximum digging radius (mm) | 10150 |
| Maximum digging depth (mm) | 6785 |
| Maximum excavation height (mm) | 9640 |
| Maximum unloading height (mm) | 6725 |
| Maximum vertical digging depth (mm) | 5845 |
