Product Description
Built for demanding construction environments, this 2020 XCMG XE225DK delivers exceptional operator control with its 22-ton working capacity and advanced hydraulic system. Powered by a robust 4HK1 engine producing 140kW at 2000 rpm, this excavator provides consistent performance across varied terrain conditions.
Operator-focused design features include:
- Enhanced cabin visibility with 9940mm maximum digging radius for precise positioning
- Superior stability through optimized 47.2 kPa ground pressure distribution
- Responsive hydraulic controls delivering 149kN bucket digging force
- Comfortable operation with water-cooled engine and efficient fuel management
With 6680mm maximum digging depth and 1.14m³ bucket capacity, this machine handles heavy excavation tasks while maintaining excellent maneuverability. The turbocharged, air-to-air intercooled engine ensures reliable power delivery, while the 35% climbing ability tackles challenging job sites. Currently located in Kunming, Yunnan, this well-maintained excavator represents proven XCMG engineering quality.
| Specifications | Value |
|---|---|
| No. | 990820 |
| Tonnage (tons) | 22 |
| Working weight (kg) | 22100 |
| Bucket capacity (m³) | 1.0-1.2 (1.14) |
| Boom length (mm) | 5680 |
| Rod length (mm) | 2910 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | 4HK1 |
| Rated power (kw/rpm) | 140/2000 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 676/1800 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 5.3 |
| Working form | Efi, 4-stroke, turbocharged, air-to-air cold |
| Ground specific pressure (Kpa) | 47.2 |
| Rotation speed (rpm) | 11.8 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 149 |
| Rod digging force (kN) | 111 |
| Maximum tractive force (kN) | 184 |
| Travel speed (km/h) | 5.3/3.0 |
| Fuel Tank (L) | 400 |
| Engine Oil changes (L) | 19.5 |
| Hydraulic System (L) | 220 |
| Total transport length (mm) | 9625 |
| Total transport width (mm) | 2990 |
| Total transport height (mm) | 3100 |
| Counterweight ground clearance (mm) | 1050 |
| Minimum ground clearance (mm) | 486 |
| Minimum turning radius of front working device (mm) | 3530 |
| Back end turning radius (mm) | 2890 |
| Total track length (mm) | 4255 |
| Track gauge (mm) | 2390 |
| Total track width (mm) | 600 |
| Maximum digging radius (mm) | 9940 |
| Maximum digging depth (mm) | 6680 |
| Maximum excavation height (mm) | 9620 |
| Maximum unloading height (mm) | 6780 |
| Maximum vertical digging depth (mm) | 5715 |
