Product Description
Built for demanding construction sites, this 2016 XCMG XE80C excavator delivers reliable 8-ton performance with proven durability. Powered by a robust 4JG1TPC engine producing 53.8kW, this machine tackles digging, grading, and demolition tasks with professional precision.
Key operational specifications include:
- Maximum digging depth of 4,160mm for deep foundation work
- 6,295mm maximum digging radius covering extensive work areas
- 51.2kN bucket digging force for tough soil conditions
- 0.3m³ bucket capacity optimized for versatile material handling
- 35° climbing ability for challenging terrain access
Hydraulic systems operate at 172 l/min main pump flow, ensuring responsive control during precision operations. Compact transport dimensions (6,144 x 2,272 x 2,682mm) allow efficient site-to-site mobility while maintaining stability through 1,750mm track gauge. Currently located in Zhejiang Lishui, this machine represents immediate productivity for contractors requiring dependable excavation capabilities without compromise.
| Specifications | Value |
|---|---|
| No. | 990792 |
| Tonnage (tons) | 8 |
| Working weight (kg) | 7460 |
| Bucket capacity (m³) | 0.3 |
| Boom length (mm) | 3720 |
| Rod length (mm) | 1622 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | 4JG1TPC |
| Rated power (kw/rpm) | 53.8/2150 |
| Maximum torque (N.m/rpm) | 255/1800 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.059 |
| Ground specific pressure (Kpa) | 33.5 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 51.2 |
| Rod digging force (kN) | 34.2 |
| Maximum tractive force (kN) | 68.5 |
| Travel speed (km/h) | 4.4/2.4 |
| Maximum flow of main pump (l/min) | 172 |
| Traveling Hydraulic Circuit (Mpa) | 27.4 |
| Rotary Hydraulic Circuit (Mpa) | 20.6 |
| Pilot Oil Circuit (MPa) | 3.5 |
| Fuel Tank (L) | 130 |
| Hydraulic Tank (L) | 115 |
| Engine Oil changes (L) | 9.7 |
| Total transport length (mm) | 6144 |
| Total transport width (mm) | 2272 |
| Total transport height (mm) | 2682 |
| Counterweight ground clearance (mm) | 797 |
| Minimum ground clearance (mm) | 393 |
| Back end turning radius (mm) | 1805 |
| Track gauge (mm) | 1750 |
| Track plate width (mm) | 450 |
| Maximum digging radius (mm) | 6295 |
| Maximum digging depth (mm) | 4160 |
| Maximum excavation height (mm) | 7135 |
| Maximum unloading height (mm) | 5030 |
| Maximum vertical digging depth (mm) | 3485 |
| Bulldozer lift or depth (mm) | 363/346 |
| Dodging plate width × height (mm) | 2200 x 396 |
