Product Description
Built for precision and control, this 2021 Case CX210C delivers 21-ton performance with operator-centric engineering. Powered by a robust 117.3 kW engine, this excavator combines reliable joint venture manufacturing with proven hydraulic efficiency across demanding jobsites in Hangzhou and beyond.
Operators benefit from exceptional visibility and intuitive handling throughout the machine's impressive work envelope. With a maximum digging reach of 9,900 mm and depth capacity extending to 6,650 mm, site positioning becomes straightforward and productive. The spacious cab design minimizes fatigue during extended shifts while providing clear sightlines to bucket positioning and surrounding ground conditions.
- Working weight: 21,200 kg with balanced stability
- Bucket digging force: 142 kN for tough material penetration
- Boom length: 5,700 mm for versatile reach
- Bucket capacity range: 0.5–1.1 m³ adaptable to task requirements
- Maximum digging height: 9,610 mm for efficient truck loading
Responsive hydraulics and smooth swing control make this CX210C a dependable choice for contractors prioritizing operator comfort alongside consistent production output.
| Specifications | Value |
|---|---|
| No. | 1021550 |
| Tonnage (tons) | 21 |
| Working weight (kg) | 21200 |
| Bucket capacity (m³) | 0.5-1.1 |
| Boom length (mm) | 5700 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Rated power (kw/rpm) | 117.3 |
| Bucket digging force (kN) | 142 |
| Rod digging force (kN) | 103 |
| Maximum digging radius (mm) | 9900 |
| Maximum digging depth (mm) | 6.65 |
| Maximum excavation height (mm) | 9610 |
| Maximum unloading height (mm) | 6810 |
| Maximum excavation radius of stop surface (mm) | 9730 |
| Maximum effective digging depth (mm) | 6650 |
