Product Description
Built for contractors managing multiple jobsites, this 2019 Case CX350B excavator from Luzhou, Sichuan delivers proven reliability as a fleet addition or backup unit. Operating at 35 tons with a 202 kW Isuzu engine, this machine maintains consistent productivity across demolition, earthmoving, and utility projects. Dual 290 l/min variable piston pumps supply hydraulic power for a maximum digging depth of 7,340 mm and reach extending to 11,170 mm radius.
- Versatile Bucket Range: 0.96–2.24 m³ capacity adapts to varied material handling requirements
- Dual Operating Modes: Standard (228.8 kN) or Extra mode (248.4 kN) bucket force matches task demands
- Extended Runtime: 580L fuel tank and water-cooled 6-cylinder engine reduce refueling downtime
- Transport-Ready Dimensions: 11,050 mm length fits standard lowboy trailers for efficient mobilization
- Proven Powertrain: Joint venture manufacturing ensures parts availability and service network support
Contractors requiring immediate capacity expansion will appreciate this machine's operational readiness and compatibility with existing Case fleet main
| Specifications | Value |
|---|---|
| No. | 1029958 |
| Tonnage (tons) | 35 |
| Working weight (kg) | 35863 |
| Bucket capacity (m³) | 0.96-2.24 |
| Boom length (mm) | 6450 |
| Rod length (mm) | 3250 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Isuzu AH-6HKIXYSS |
| Rated power (kw/rpm) | 202/2000 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 115 x 125 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 7.79 |
| Ground specific pressure (Kpa) | 51 |
| Rotation speed (rpm) | 9.8 |
| Bucket digging force (kN) | 228.8(Standard mode)/248.4(Extra mode) |
| Rod digging force (kN) | 163.9(Standard Mode)/178.0(Plus mode) |
| Travel speed (km/h) | 3.5/5.5 |
| Rotary hydraulic motor type | Quantitative axial piston motor |
| Type of walking hydraulic motor | Variable axial piston motor |
| Maximum flow of main pump (l/min) | 290 * 2 + 30.5 |
| Main pump type | Variable axial piston pump ×2+ gear pump |
| Pilot Oil Circuit (MPa) | 3.9 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-150 x 1210 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-170 x 1748 |
| Boom cylinders - Number × diameter × stroke (mm) | 2-145 x 1495 |
| Fuel Tank (L) | 580 |
| Hydraulic Tank (L) | 175 |
| Engine Oil changes (L) | 38 |
| Coolant (L) | 30 |
| Hydraulic System (L) | 350 |
| Total transport length (mm) | 11050 |
| Total transport width (mm) | 3400 |
| Total transport height (mm) | 3260 |
| Full cab height (mm) | 3190 |
| Counterweight ground clearance (mm) | 1210 |
| Minimum ground clearance (mm) | 480 |
| Minimum turning radius of front working device (mm) | 4500 |
| Back end turning radius (mm) | 3450 |
| Total track length (mm) | 4980 |
| Track gauge (mm) | 2600 |
| Track plate width (mm) | 800 |
| Total track width (mm) | 3400 |
| Track ground length (mm) | 4040 |
| Maximum digging radius (mm) | 11170 |
| Maximum digging depth (mm) | 7340 |
| Maximum excavation height (mm) | 10370 |
| Maximum unloading height (mm) | 7230 |
| Maximum vertical digging depth (mm) | 6350 |
| Maximum excavation radius of stop surface (mm) | 10980 |
| Maximum effective digging depth (mm) | 7190 |
