Product Description
Built in 2022, this Case CX80 mini excavator delivers proven performance with the backing of a globally trusted brand. Operating at 8 tons with an 8,430 kg working weight, this machine combines compact dimensions (6,660 mm transport length) with serious capability—reaching a maximum digging depth of 4,180 mm and a digging radius of 7,030 mm. Power comes from a reliable Isuzu AU-4LE2X engine producing 40 kW at 2,000 rpm, paired with dual variable axial piston pumps delivering 68 l/min each for responsive hydraulic performance.
Currently located in Hangzhou, Zhejiang, this excavator features a 0.18-0.34 m³ bucket capacity and impressive digging forces: 56.9 kN bucket force and 38.3 kN arm force. Case's joint venture manufacturing ensures quality control, while the brand's extensive dealer network guarantees parts availability and service support long after purchase. With strong resale value retention and a proven track record in Asian markets, Case equipment represents a secure investment for contractors seeking dependable machinery without the premium price of new units.
- 8-ton class with Isuzu diesel engine
- Maximum digging depth: 4,180 mm
- Dual variable piston pumps for smooth operation
| Specifications | Value |
|---|---|
| No. | 1016912 |
| Tonnage (tons) | 8 |
| Working weight (kg) | 8430 |
| Bucket capacity (m³) | 0.18-0.34 |
| Boom length (mm) | 3500 |
| Rod length (mm) | 1710 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Isuzu AU-4LE2X |
| Rated power (kw/rpm) | 40/2000 |
| Cylinder diameter × stroke (mm) | 85 x 96 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 2.179 |
| Ground specific pressure (Kpa) | 38 |
| Rotation speed (rpm) | 9.5 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 56.9 |
| Rod digging force (kN) | 38.3 |
| Travel speed (km/h) | 3.4/5.1 |
| Rotary hydraulic motor type | Quantitative axial piston motor |
| Type of walking hydraulic motor | Variable axial piston motor |
| Maximum flow of main pump (l/min) | 68 * 2 + 21.4 |
| Main pump type | Variable axial piston pump ×2+ gear pump |
| Pilot Oil Circuit (MPa) | 4.2 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-85 x 665 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-95 x 797 |
| Boom cylinders - Number × diameter × stroke (mm) | 1-110 x 911 |
| Fuel Tank (L) | 100 |
| Hydraulic Tank (L) | 50 |
| Engine Oil changes (L) | 9 |
| Coolant (L) | 10.2 |
| Hydraulic System (L) | 97.3 |
| Total transport length (mm) | 6660 |
| Total transport width (mm) | 2320 |
| Total transport height (mm) | 2700 |
| Full cab height (mm) | 2700 |
| Counterweight ground clearance (mm) | 750 |
| Minimum ground clearance (mm) | 360 |
| Minimum turning radius of front working device (mm) | 2750 |
| Back end turning radius (mm) | 1660 |
| Total track length (mm) | 2850 |
| Track gauge (mm) | 1870 |
| Track plate width (mm) | 450 |
| Total track width (mm) | 2320 |
| Track ground length (mm) | 2210 |
| Maximum digging radius (mm) | 7030 |
| Maximum digging depth (mm) | 4180 |
| Maximum excavation height (mm) | 6390 |
| Maximum unloading height (mm) | 4390 |
| Maximum vertical digging depth (mm) | 3080 |
| Bulldozer lift or depth (mm) | 420/210 |
| Dodging plate width × height (mm) | 2320 x 450 |
| Maximum excavation radius of stop surface (mm) | 6890 |
| Boom turning Angle (left/right °) | 80/50 |
| Maximum effective digging depth (mm) | 3780 |
