2019 Caterpillar 301.4C
Product Description
With a working weight of 1380-1558 kg, the 2019 Caterpillar 301.4C mini excavator is a reliable choice for those in need of compact yet powerful machinery. Located in Sichuan, China, this model is equipped with a Yanmar 3TNV76 engine, delivering 13.2 kW of power and featuring a water-cooling system for optimal performance. Its robust design includes a backhoe bucket, providing a bucket digging force of 16 kN, and a maximum travel speed of 2.5 km/h. The 301.4C offers a maximum digging depth of 2240 mm and a maximum excavation height of 3390 mm, making it versatile for various construction tasks.
- Brand: Caterpillar, known for high reliability and parts availability
- Model: 301.4C, ensuring strong resale value
- Engine: Yanmar 3TNV76, 13.2 kW, 3-cylinder, 1.116 L displacement
- Working Hydraulic Circuit: 20 Mpa, supporting efficient operation
- Total transport dimensions: 3645 mm (length) x 990 mm (width) x 2276 mm (height)
| Specifications | Value |
|---|---|
| No. | 1057385 |
| Tonnage (tons) | 1 |
| Working weight (kg) | 1380-1558 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar Yanmar 3TNV76 |
| Rated power (kw/rpm) | 13.2 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 3 |
| Displacement (L) | 1.116 |
| Climbing ability (%) | 30 ° / 58% |
| Bucket digging force (kN) | 16 |
| Rod digging force (kN) | 7.1 |
| Travel speed (km/h) | 2.5 |
| Maximum flow of main pump (l/min) | 35 |
| Traveling Hydraulic Circuit (Mpa) | 20 |
| Rotary Hydraulic Circuit (Mpa) | 15 |
| Working Hydraulic Circuit (Mpa) | 20 |
| Fuel Tank (L) | 24 |
| Hydraulic Tank (L) | 20 |
| Total transport length (mm) | 3645 |
| Total transport width (mm) | 990 |
| Total transport height (mm) | 2276 |
| Full cab height (mm) | 2276 |
| Back end turning radius (mm) | 1075 |
| Total track length (mm) | 1460 |
| Track plate width (mm) | 230 |
| Maximum digging radius (mm) | 3700 |
| Maximum digging depth (mm) | 2240 |
| Maximum excavation height (mm) | 3390 |
| Maximum unloading height (mm) | 2370 |
| Maximum vertical digging depth (mm) | 1640 |
| Bulldozer lift or depth (mm) | 264/211 |
| Dodging plate width × height (mm) | 980 x 232 |
| Maximum excavation radius of stop surface (mm) | 3650 |
| Boom turning Angle (left/right °) | 49 ° 73 ° / |
see more
Overview
No.1057385
Brand Name：
CaterpillarModel Number：
301.4CYear：
2019
Location：
Sichuan China
Pub Date：
