2021 Caterpillar 301.4C








Product Description
This 2021 Caterpillar 301.4C mini excavator represents a reliable compact earthmoving solution from one of the industry's most trusted manufacturers. Currently located in Hunan, China, this machine offers approximately three years of operational experience while retaining substantial service life. The Cat 301.4C is engineered for confined job sites, utility work, and landscaping applications where maneuverability and precision are essential.
Key features include:
- Compact dimensions for urban construction and restricted access areas
- Caterpillar's proven hydraulic system for responsive control
- Low ground pressure to minimize surface disturbance
- Efficient fuel consumption reducing operational costs
- Durable undercarriage designed for extended wear life
This unit is available for international shipping and represents a cost-effective option for contractors seeking dependable compact excavation equipment with established manufacturer support worldwide.
| Specifications | Value |
|---|---|
| No. | 1094300 |
| Tonnage (tons) | 1 |
| Working weight (kg) | 1380-1558 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Yanmar Yanmar 3TNV76 |
| Rated power (kw/rpm) | 13.2 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 3 |
| Displacement (L) | 1.116 |
| Climbing ability (%) | 30 ° / 58% |
| Bucket digging force (kN) | 16 |
| Rod digging force (kN) | 7.1 |
| Travel speed (km/h) | 2.5 |
| Maximum flow of main pump (l/min) | 35 |
| Traveling Hydraulic Circuit (Mpa) | 20 |
| Rotary Hydraulic Circuit (Mpa) | 15 |
| Working Hydraulic Circuit (Mpa) | 20 |
| Fuel Tank (L) | 24 |
| Hydraulic Tank (L) | 20 |
| Total transport length (mm) | 3645 |
| Total transport width (mm) | 990 |
| Total transport height (mm) | 2276 |
| Full cab height (mm) | 2276 |
| Back end turning radius (mm) | 1075 |
| Total track length (mm) | 1460 |
| Track plate width (mm) | 230 |
| Maximum digging radius (mm) | 3700 |
| Maximum digging depth (mm) | 2240 |
| Maximum excavation height (mm) | 3390 |
| Maximum unloading height (mm) | 2370 |
| Maximum vertical digging depth (mm) | 1640 |
| Bulldozer lift or depth (mm) | 264/211 |
| Dodging plate width × height (mm) | 980 x 232 |
| Maximum excavation radius of stop surface (mm) | 3650 |
| Boom turning Angle (left/right °) | 49 ° 73 ° / |
Overview
No.1094300
Brand Name:
CaterpillarModel Number:
301.4CYear:
2021
Location:
Hunan China
