2012 Caterpillar 306D
Product Description
Designed for precision work in confined spaces, this 2012 Caterpillar 306D hydraulic excavator delivers exceptional operator control and all-day comfort. Ergonomic joystick controls respond instantly to input, allowing smooth bucket movements and precise digging angles even in tight urban environments. Panoramic cabin glazing provides unobstructed sightlines to attachment points, trench edges, and surrounding obstacles, reducing blind spots and improving job site safety.
Stability remains consistent across varied terrain thanks to the robust undercarriage and optimized weight distribution. Operators benefit from reduced fatigue during extended shifts, with intuitive control placement and minimal vibration transfer to the cabin. Currently located in Guizhou, this machine combines Caterpillar's proven hydraulic technology with practical features that experienced operators value.
- Superior visibility through large cabin windows
- Responsive hydraulic controls for accurate operation
- Stable platform for sloped and uneven ground
- Comfortable ergonomics for long working hours
| Specifications | Value |
|---|---|
| No. | 1029788 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5775 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | 4M40 |
| Rated power (kw/rpm) | 41 |
| Cylinder diameter × stroke (mm) | 95 x100 |
| Rotation speed (rpm) | 8.8 RPM |
| Bucket digging force (kN) | 38.6 |
| Rod digging force (kN) | 25.5 |
| Maximum tractive force (kN) | 48.2 kN |
| Travel speed (km/h) | 4.8 km/h |
| Turning torque (Nm) | 12.3 kN·m |
| Main overflow set pressure (Mpa) | 24500 |
| Maximum flow of main pump (l/min) | 152 |
| Fuel Tank (L) | 135 L |
| Hydraulic Tank (L) | 57 L |
| Engine Oil changes (L) | 11.2 L |
| Hydraulic System (L) | 85 L |
| Track plate width (mm) | 400 mm |
