2020 Caterpillar 312B

Name: Used Excavators 2020 Caterpillar 312B
Brand: Caterpillar
SKU: USED-1057216
Availability: InStock
Rating: 4.1 (62 reviews)

1/5

Product Description

With a working weight of 12,433 kg and a bucket capacity ranging from 0.35 to 0.78 m³, this 2020 Caterpillar 312B excavator is an ideal addition to any contractor's fleet. Located in Guangdong, China, it serves as a reliable backup or primary unit, ensuring continuous operation and productivity. Powered by a CATERPILLAR 3064T engine with a rated power of 67.9 kW at 1900 rpm, this machine delivers consistent performance. Its ground pressure of 39 Kpa and travel speed of 5.5 km/h make it versatile for various terrains. Equipped with a 250 L fuel tank and robust hydraulic system, the 312B is ready for long hours of demanding work. Key dimensions include a total transport width of 2490 mm and a full cab height of 2760 mm, ensuring easy maneuverability and transport. Whether you need to dig, load, or move, this excavator is a dependable choice for your fleet.

Specifications	Value
No.	1057216
Tonnage (tons)	12
Working weight (kg)	12433
Bucket capacity (m³)	0.46/0.35/0.78
power	Traditional power
manufacturer	Joint venture/Import
bucket	backhoe
Engine type	CATERPILLAR 3064T
Rated power (kw/rpm)	67.9/1900(62.6/1900)
Displacement (L)	4.2
Ground specific pressure (Kpa)	39
Travel speed (km/h)	5.5
Fuel Tank (L)	250
Engine Oil changes (L)	13
Coolant (L)	15.5
Hydraulic System (L)	162
Total transport width (mm)	2490
Full cab height (mm)	2760
Counterweight ground clearance (mm)	920
Minimum ground clearance (mm)	440
Back end turning radius (mm)	2130
Track gauge (mm)	1990
Track plate width (mm)	500
Track ground length (mm)	2780
Maximum digging depth (mm)	5130
Maximum excavation height (mm)	8230
Maximum unloading height (mm)	5860
Maximum vertical digging depth (mm)	4430
Maximum excavation radius of stop surface (mm)	7790
