2016 Caterpillar 312D
Product Description
Built in 2016, this Caterpillar 312D excavator delivers proven performance backed by the world's most trusted heavy equipment brand. Operating at 12 tons with a robust C4.2 ACERT engine producing 72kW, this machine handles demanding excavation tasks with a maximum digging depth of 5,840mm and bucket capacity of 0.52m³. Caterpillar's engineering ensures parts remain readily available worldwide, protecting your investment and minimizing downtime when maintenance is required.
Currently located in Jiangxi Ji'an, this 312D represents smart buying for operations requiring dependable mid-size excavation power. Key advantages include:
- Global parts network ensures rapid component sourcing and service support
- Proven water-cooled engine design with 4.25L displacement for consistent output
- Strong resale value retention compared to competing brands
- Hydraulic system rated at 3.05MPa with 127L/min pump flow for responsive operation
- Compact transport dimensions (7,590mm length) facilitate jobsite mobility
Caterpillar's reputation for durability translates directly into lower total ownership costs. When purchasing used equipment, brand reliability determines long-term profitabi
| Specifications | Value |
|---|---|
| No. | 1014677 |
| Tonnage (tons) | 12 |
| Working weight (kg) | 12920 |
| Bucket capacity (m³) | 0.52 |
| Boom length (mm) | 2800 |
| Rod length (mm) | 3000 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | C4.2ACERT |
| Rated power (kw/rpm) | 72/2200 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 102 x 130 |
| Displacement (L) | 4.25 |
| Rotation speed (rpm) | 12.4 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 96 |
| Rod digging force (kN) | 62 |
| Travel speed (km/h) | 3.4/5.5 |
| Maximum flow of main pump (l/min) | 127 |
| Traveling Hydraulic Circuit (Mpa) | 3.5 |
| Rotary Hydraulic Circuit (Mpa) | 2.3 |
| Hydraulic crushing pipeline is standard | no |
| Working Hydraulic Circuit (Mpa) | 3.05 |
| Pilot Oil Circuit (MPa) | 4.12 |
| Bucket cylinders - Number × diameter × stroke (mm) | 100 x 939 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 120 x 1197 |
| Boom cylinders - Number × diameter × stroke (mm) | 110 x 1015 |
| Fuel Tank (L) | 250 |
| Hydraulic Tank (L) | 150 |
| Engine Oil changes (L) | 19.5 |
| Coolant (L) | 17.9 |
| Hydraulic System (L) | 162(including fuel tank) |
| Total transport length (mm) | 7590 |
| Total transport width (mm) | 2590 |
| Total transport height (mm) | 2970 |
| Full cab height (mm) | 2760 |
| Counterweight ground clearance (mm) | 915 |
| Minimum ground clearance (mm) | 430 |
| Total track length (mm) | 3490 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Total track width (mm) | 2590 |
| Track ground length (mm) | 2780 |
| Maximum digging depth (mm) | 5840 |
| Maximum excavation height (mm) | 8580 |
| Maximum unloading height (mm) | 6210 |
| Maximum vertical digging depth (mm) | 5160 |
| Bulldozer lift or depth (mm) | No bulldozer |
| Dodging plate width × height (mm) | No bulldozer |
| Maximum excavation radius of stop surface (mm) | 8430 |
| Maximum effective digging depth (mm) | 5640 |
Overview
No.1014677
Brand Name：
CaterpillarModel Number：
312DYear：
2016
Location：
Jiangxi China
Pub Date：
