2016 Caterpillar 313D
Product Description
Expand your fleet capacity with this 2016 Caterpillar 313D excavator, currently stationed in Hangzhou, Zhejiang. Operating at 13 tons working weight with a 0.52 m³ bucket capacity, this compact machine delivers consistent performance across urban construction, utility work, and residential projects. Powered by the Cat C4.2 ACERT engine producing 67 kW net power, it meets US EPA Tier 3 and EU Stage IIIA emission standards while maintaining fuel efficiency from its 250L tank.
Key operational specifications include:
- Maximum digging depth of 5,580 mm with 8,220 mm reach at ground level
- Bucket digging force: 82 kN; stick digging force: 63 kN
- Hydraulic system: 127 L/min main pump flow at 30.5 MPa
- Compact transport dimensions: 7,610 mm (L) × 2,490 mm (W) × 2,830 mm (H)
- 500 mm standard track plates with 41.8 kPa ground pressure
Ideal as a backup unit during peak seasons or for diversifying job-site capabilities, this 313D integrates seamlessly into existing Caterpillar fleets with standardized service protocols and parts compatibility.
| Specifications | Value |
|---|---|
| No. | 1040349 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 13430 |
| Bucket capacity (m³) | 0.52 |
| Boom length (mm) | 4650 |
| Rod length (mm) | 2500 |
| Country of origin | Xuzhou, Jiangsu |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar Cat C4.2 ACERT |
| Rated power (kw/rpm) | 67 (Net power) |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 102 x 130 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 4.25 |
| Working form | Meets the emission requirements of US EPA Tier 3 and European IIIA Directive 97/68/EC. |
| Ground specific pressure (Kpa) | 41.8 (with 500mm track plate) |
| Rotation speed (rpm) | 12.4 |
| Bucket digging force (kN) | 82 |
| Rod digging force (kN) | 63 |
| Maximum tractive force (kN) | 114 |
| Travel speed (km/h) | 5.5 |
| Main overflow set pressure (Mpa) | 30.5 |
| Maximum flow of main pump (l/min) | 127 |
| Traveling Hydraulic Circuit (Mpa) | 35 |
| Rotary Hydraulic Circuit (Mpa) | 23 |
| Pilot Oil Circuit (MPa) | 41.2 |
| Pilot pump flow (L/min) | 21.9 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1 x 100 x 939 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1 x 120 x 1197 |
| Boom cylinders - Number × diameter × stroke (mm) | 2 x 110 x 1015 |
| Fuel Tank (L) | 250 |
| Hydraulic Tank (L) | 150 |
| Engine Oil changes (L) | 19.5 |
| Coolant (L) | 17.9 |
| Hydraulic System (L) | 162 (including fuel tank) |
| Total transport length (mm) | 7610 |
| Total transport width (mm) | 2490 |
| Total transport height (mm) | 2830 (to top of boom) |
| Full cab height (mm) | 2760 |
| Counterweight ground clearance (mm) | 915 |
| Minimum ground clearance (mm) | 430 |
| Back end turning radius (mm) | 2140 |
| Total track length (mm) | 3490 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 (standard) |
| Total track width (mm) | 2490 |
| Maximum digging depth (mm) | 5580 |
| Maximum unloading height (mm) | 6060 |
| Maximum vertical digging depth (mm) | 5040 |
| Bulldozer lift or depth (mm) | There is no |
| Dodging plate width × height (mm) | There is no |
| Maximum excavation radius of stop surface (mm) | 8220 |
| Boom turning Angle (left/right °) | There is no |
| Maximum effective digging depth (mm) | 5380 |
Overview
No.1040349
Brand Name：
CaterpillarModel Number：
313DYear：
2016
Location：
Zhejiang China
Pub Date：
