2016 Caterpillar 313D
Product Description
Built for precision excavation and all-day productivity, this 2016 Caterpillar 313D delivers 13 tons of reliable digging power on any job site. Powered by the Cat C4.2 ACERT engine generating 67 kW of net power, this machine tackles trenching, grading, and material handling with consistent performance. The 0.52 m³ bucket capacity and 82 kN bucket digging force handle demanding soil conditions, while the 8,220 mm maximum excavation radius provides exceptional reach for loading trucks and working across wide areas.
Key specifications include:
- Working weight: 13,430 kg with stable 41.8 kPa ground pressure
- Maximum digging depth: 5,580 mm for deep foundation work
- Hydraulic system: 127 L/min main pump flow at 30.5 MPa for responsive control
- Transport dimensions: 7,610 mm length × 2,490 mm width for easy site mobility
- Fuel capacity: 250 L tank supports extended operation between refills
- Compliance: Meets US EPA Tier 3 and EU Stage IIIA emission standards
Currently located in Shaoxing, Zhejiang, this water-cooled excavator arrives site-ready with proven Caterpillar engineering and the capacity to start digging immediately.
| Specifications | Value |
|---|---|
| No. | 1048503 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 13430 |
| Bucket capacity (m³) | 0.52 |
| Boom length (mm) | 4650 |
| Rod length (mm) | 2500 |
| Country of origin | Xuzhou, Jiangsu |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar Cat C4.2 ACERT |
| Rated power (kw/rpm) | 67 (Net power) |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 102 x 130 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 4.25 |
| Working form | Meets the emission requirements of US EPA Tier 3 and European IIIA Directive 97/68/EC. |
| Ground specific pressure (Kpa) | 41.8 (with 500mm track plate) |
| Rotation speed (rpm) | 12.4 |
| Bucket digging force (kN) | 82 |
| Rod digging force (kN) | 63 |
| Maximum tractive force (kN) | 114 |
| Travel speed (km/h) | 5.5 |
| Main overflow set pressure (Mpa) | 30.5 |
| Maximum flow of main pump (l/min) | 127 |
| Traveling Hydraulic Circuit (Mpa) | 35 |
| Rotary Hydraulic Circuit (Mpa) | 23 |
| Pilot Oil Circuit (MPa) | 41.2 |
| Pilot pump flow (L/min) | 21.9 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1 x 100 x 939 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1 x 120 x 1197 |
| Boom cylinders - Number × diameter × stroke (mm) | 2 x 110 x 1015 |
| Fuel Tank (L) | 250 |
| Hydraulic Tank (L) | 150 |
| Engine Oil changes (L) | 19.5 |
| Coolant (L) | 17.9 |
| Hydraulic System (L) | 162 (including fuel tank) |
| Total transport length (mm) | 7610 |
| Total transport width (mm) | 2490 |
| Total transport height (mm) | 2830 (to top of boom) |
| Full cab height (mm) | 2760 |
| Counterweight ground clearance (mm) | 915 |
| Minimum ground clearance (mm) | 430 |
| Back end turning radius (mm) | 2140 |
| Total track length (mm) | 3490 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 (standard) |
| Total track width (mm) | 2490 |
| Maximum digging depth (mm) | 5580 |
| Maximum unloading height (mm) | 6060 |
| Maximum vertical digging depth (mm) | 5040 |
| Bulldozer lift or depth (mm) | There is no |
| Dodging plate width × height (mm) | There is no |
| Maximum excavation radius of stop surface (mm) | 8220 |
| Boom turning Angle (left/right °) | There is no |
| Maximum effective digging depth (mm) | 5380 |
Overview
No.1048503
Brand Name：
CaterpillarModel Number：
313DYear：
2016
Location：
Zhejiang China
Pub Date：
